Home > Products > Gasoline /LPG Forklift Truck > 2.5 Ton LPG Forklift
2.5 Ton LPG Forklift
Negotiable
/ Set
1 Set(Min.Order)
- 1000 Set / Sets per Month
- Shanghai
- T/T
You May Like
Product Details
Condition: | New | Place of Origin: | Shanghai, China | Brand Name: | GP |
Model Number: | CPQYD25 | Type: | Powered Pallet Truck | Power Souce: | Gasoline Engine |
Rated Loading Capacity: | 2500kg | Max. Lifting Height: | 3000mm | Min. Lifting Height: | 0mm |
Fork Length: | 1070mm | Fork Width: | 120mm | Overall Dimensions: | 2580*1150*2060mm |
Product Description
Specifications
1)Germany Technology.2)Europe Standard.
3)Forceful Power.
4)Energy Conservation and Environmental Protection
General | Manufacturer | SHANGHAI GP | |||||||
1 | Model | CPQ(Y)D20 | CPQ(Y)D25 | CPQ(Y)D30 | CPQ(Y)D35 | ||||
2 | Rated capacity | kg | 2000 | 2500 | 3000 | 3500 | |||
3 | Load center | mm | 500 | ||||||
4 | Gearbox change speed type | Hydraulic/ Mechanical | |||||||
5 | Power type | Gasoline / LPG | |||||||
6 | Tire type | Front/ Rear | Pneumatic | ||||||
7 | (X=)Wheels | Front/ Rear | 2/2 | ||||||
Dimensions | 8 | Lift height | mm | 3000 | |||||
9 | Free lift height | mm | 140 | 145 | |||||
10 | Fork size | L*W*T | mm | 1070x120x40 | 1070x120x40 | 1070x125x45 | 1070x130x45 | ||
11 | Mast tilt angle | /Fwd/Bwd | deg | 6/12 | |||||
12 | () Overall length (without fork) | mm | 2510 | 2580 | 2720 | 2775 | |||
13 | Overall width | mm | 1150 | 1225 | |||||
14 | () Mast height fork lowered | mm | 2050 | 2080 | 2230 | ||||
15 | Overall height fork raised | mm | 4040 | 4272 | |||||
16 | Overall height (overhead guard) | mm | 2060 | 2090 | |||||
17 | () Turning radius (outside) | mm | 2170 | 2240 | 2460 | 2540 | |||
18 | Load distance (centerline of front axle to front face of forks | mm | 484 | 489 | 494 | 500 | |||
19 | Wheel base | mm | 1650 | 1700 | |||||
20 | Tread | Front | mm | 970 | 1000 | ||||
21 | Rear | mm | 970 | ||||||
22 | Min. Under-clearance (full load / no load ) | () Bottom of mast | mm | 85/105 | 110/135 | ||||
23 | Bottom of frame | mm | 115/120 | 135/140 | |||||
Performance | 24 | Speed | Travel speed | With load | km/h | 17 | 18 | ||
25 | Without load | km/h | 19 | 19 | |||||
26 | Lifting speed | With load | mm/sec | 470 | 430 | 400 | |||
27 | Without load | mm/sec | 600 | 500 | 450 | ||||
28 | Max. Drawbar pull | With/ without load | kg | 1250/850 | 1250/850 | 1100/1000 | 1304/1190 | ||
29 | 1650/850 | 1650/850 | 1350/1000 | 1696/1190 | |||||
30 | Max.Gradeability | With/ without load | % (fan) | 20/20 | 17/18 | 15/18 | 15/18 | ||
21/22 | 18/19 | 19/20 | 15/18 | ||||||
Weight | 31 | Self weight | kg | 3550 | 3880 | 4380 | 4750 | ||
32 | Weight distribution | With load | Front | kg | 4730 | 5480 | 6455 | 7320 | |
33 | Rear | kg | 590 | 700 | 825 | 930 | |||
34 | Without load | Front | kg | 1520 | 1465 | 1720 | 2040 | ||
35 | Rear | kg | 1800 | 2215 | 2560 | 2710 | |||
Tyre | 36 | Tyre | Size | Front | 7.00-12-12PR | 28x9-15-14PR | |||
37 | Rear | 6.00-9-10PR | 6.50-10-10PR | ||||||
Brake | 38 | Brake | Service | - Hydraulic-Foot pedal | |||||
39 | Parking | - Mechanical-Hand lever | |||||||
Transmission | 40 | Battery | Voltage / Capacity | V/AH | 12/100 | ||||
41 | Internal combustion engine | Model for option | NISSAN / MITSUBISHI / GQ- 4Y | ||||||
42 | Transmission | Type | / Hydraulic/Mechanical | ||||||
43 | shift (/ Fwd/Rvs) | 1/1 (2/2) | |||||||
44 | Work pressure | Mpa | 17.5 |
