3T LP Gas FORKLIFT

3T LP Gas FORKLIFT thumbnail-1
3T LP Gas FORKLIFT thumbnail-2
3T LP Gas FORKLIFT thumbnail-3
3T LP Gas FORKLIFT photo-1
3T LP Gas FORKLIFT photo-2
3T LP Gas FORKLIFT photo-3
US$ 8,000 - 53,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
GP
Contact Supplier Request Quote Chat Now
Shanghai Gather Power Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shanghai, China
Brand Name GP
Model Number CPQD30
Type Other
Power Souce Gasoline Engine
Certification ISO9001
After-sales Service Provided Engineers available to service machinery overseas
Product Description
General   Manufacturer   GP
1 Model   CPQD20 CPQD25 CPQD30 CPQD35
CPQ20 CPQ25 CPQ30 CPQ35
2 Rated capacity kg 2000 2500 3000 3500
3 Load center mm 500
4 Gearbox change speed type   Hydraulic/Mechanical
5 Power type   Gasoline / LPG
6 Tire type Front/Rear   Pneumatic
7 Wheels Front/Rear   2*2/2
Dimensions 8 Lift height mm 3000
9 Free lift height mm 140 145 150
10 Fork size L*W*T mm 920*122*40 1070*122*40 1070*125*45 1070*130*45
11 Mast tilt angle Fwd/Bwd deg 6/12
12 Overall length (without fork) mm 2513 2583 2698 2725
13 Overall width mm 1150 1225 1225
14 Mast height fork lowered mm 1995 2070 2160
15 Overall height fork raised mm 4030 4250 3290
16 Overall height (overhead guard) mm 2070 2090
17 Turning radius (outside) mm 2170 2240 2400 2450
18 Load distance (centerline of front axle to front face of forks) mm 483 498
19 Minimum Aisle -90 stack(Add load length and clearance) mm 2640 2710 2885
20 Wheel base mm 1600 1700
21 Tread Front mm 970 1000
22 Rear mm 970
23 Min. Under-clearance Bottom of mast mm 110 135 145
24 Bottom of frame mm 115 140 140
Performance 25 Speed Travel Max. With load km/h 17 18
26 Without load km/h 19.5 19.5
27 Lifting With load km/h 570 450 380
28 Without load km/h 600 500 450
29 Lowering With load km/h 450 420
30 Without load km/h 550 500 460
31 Max. Drawbar pull With/without load kg 1250/850 1250/850 1100/1000 1304/1190
32 1650/850 1650/850 1350/1000 1696/1190
33 Max.Gradeability With/without load % (fan) 20/20 17/18 15/18 15/18
21/22 18/19 19/20 15/18
Weight 34 Service weight kg 3410 3770 4370 4750
35 Weight distribution With load Front kg 4730 5480 6455 7320
36 Rear kg 590 700 825 930
37 Without load Front kg 1520 1465 1720 2040
38 Rear kg 1800 2215 2560 2710
Tyre 39 Tyre Size Front   7.00-12-12PR 28*9-15-12PR
40 Rear   6.00-9-10PR 6.50-10-10PR
Brake 41 Brake Service   Hydraulic-Foot pedal
42 Parking   Mechanical-Hand lever
Transmission 43 Battery Voltage / Capacity V/AH 12/100
44 Internal combustion engine Model   MITSUBISHI / NISSAN / HW491/ GQ-4Y
45 Rated horsepower Kw/rpm 42.5/2500 45.6/2700
46 Rated torque N.m/rpm 161/1600 185/1600
47 Number of cylinder   4
48 Displacement cc 2.35 2.488
49 Fuel tank capacity lit 70 70
50 Transmission Type   Hydraulic/Mechanical
51 Shift (Fwd/Rvs)   1/1 (2/2)
  52 Work pressure Mpa 17.5



Product Pictures



 3T LP Gas FORKLIFT3T LP Gas FORKLIFT3T LP Gas FORKLIFT
