Help Center6 Ton Gas Forklift & LPG Forklift Truck for Sale
Related Products
-
7 Ton Gas Forklift & LPG Forklift TruckUS$ 10,000 - 53,000MOQ: 1 Piece -
1-1.8 Ton Mini LPG ForkliftNegotiableMOQ: 1 Set
-
2-3.5Ton Gasoline/LPG Forklift TruckNegotiableMOQ: 1 Unit
-
4.0-5.0T Gasoline/ LPG Forklift TruckNegotiableMOQ: 1 Unit
-
5-7 T Gasoline/LPG Forklift TruckUS$ 7,000 - 7,000MOQ: 1 Unit
| General | Manufacturer | GP | |||||||
| 1 | Model | CPQD20 | CPQD25 | CPQD30 | CPQD35 | ||||
| CPQ20 | CPQ25 | CPQ30 | CPQ35 | ||||||
| 2 | Rated capacity | kg | 2000 | 2500 | 3000 | 3500 | |||
| 3 | Load center | mm | 500 | ||||||
| 4 | Gearbox change speed type | Hydraulic/Mechanical | |||||||
| 5 | Power type | Gasoline / LPG | |||||||
| 6 | Tire type | Front/Rear | Pneumatic | ||||||
| 7 | Wheels | Front/Rear | 2*2/2 | ||||||
| Dimensions | 8 | Lift height | mm | 3000 | |||||
| 9 | Free lift height | mm | 140 | 145 | 150 | ||||
| 10 | Fork size | L*W*T | mm | 920*122*40 | 1070*122*40 | 1070*125*45 | 1070*130*45 | ||
| 11 | Mast tilt angle | Fwd/Bwd | deg | 6/12 | |||||
| 12 | Overall length (without fork) | mm | 2513 | 2583 | 2698 | 2725 | |||
| 13 | Overall width | mm | 1150 | 1225 | 1225 | ||||
| 14 | Mast height fork lowered | mm | 1995 | 2070 | 2160 | ||||
| 15 | Overall height fork raised | mm | 4030 | 4250 | 3290 | ||||
| 16 | Overall height (overhead guard) | mm | 2070 | 2090 | |||||
| 17 | Turning radius (outside) | mm | 2170 | 2240 | 2400 | 2450 | |||
| 18 | Load distance (centerline of front axle to front face of forks) | mm | 483 | 498 | |||||
| 19 | Minimum Aisle -90 stack(Add load length and clearance) | mm | 2640 | 2710 | 2885 | ||||
| 20 | Wheel base | mm | 1600 | 1700 | |||||
| 21 | Tread | Front | mm | 970 | 1000 | ||||
| 22 | Rear | mm | 970 | ||||||
| 23 | Min. Under-clearance | Bottom of mast | mm | 110 | 135 | 145 | |||
| 24 | Bottom of frame | mm | 115 | 140 | 140 | ||||
| Performance | 25 | Speed | Travel Max. | With load | km/h | 17 | 18 | ||
| 26 | Without load | km/h | 19.5 | 19.5 | |||||
| 27 | Lifting | With load | km/h | 570 | 450 | 380 | |||
| 28 | Without load | km/h | 600 | 500 | 450 | ||||
| 29 | Lowering | With load | km/h | 450 | 420 | ||||
| 30 | Without load | km/h | 550 | 500 | 460 | ||||
| 31 | Max. Drawbar pull | With/without load | kg | 1250/850 | 1250/850 | 1100/1000 | 1304/1190 | ||
| 32 | 1650/850 | 1650/850 | 1350/1000 | 1696/1190 | |||||
| 33 | Max.Gradeability | With/without load | % (fan) | 20/20 | 17/18 | 15/18 | 15/18 | ||
| 21/22 | 18/19 | 19/20 | 15/18 | ||||||
| Weight | 34 | Service weight | kg | 3410 | 3770 | 4370 | 4750 | ||
| 35 | Weight distribution | With load | Front | kg | 4730 | 5480 | 6455 | 7320 | |
| 36 | Rear | kg | 590 | 700 | 825 | 930 | |||
| 37 | Without load | Front | kg | 1520 | 1465 | 1720 | 2040 | ||
| 38 | Rear | kg | 1800 | 2215 | 2560 | 2710 | |||
| Tyre | 39 | Tyre | Size | Front | 7.00-12-12PR | 28*9-15-12PR | |||
| 40 | Rear | 6.00-9-10PR | 6.50-10-10PR | ||||||
| Brake | 41 | Brake | Service | Hydraulic-Foot pedal | |||||
| 42 | Parking | Mechanical-Hand lever | |||||||
| Transmission | 43 | Battery | Voltage / Capacity | V/AH | 12/100 | ||||
| 44 | Internal combustion engine | Model | MITSUBISHI / NISSAN / HW491/ GQ-4Y | ||||||
| 45 | Rated horsepower | Kw/rpm | 42.5/2500 | 45.6/2700 | |||||
| 46 | Rated torque | N.m/rpm | 161/1600 | 185/1600 | |||||
| 47 | Number of cylinder | 4 | |||||||
| 48 | Displacement | cc | 2.35 | 2.488 | |||||
| 49 | Fuel tank capacity | lit | 70 | 70 | |||||
| 50 | Transmission | Type | Hydraulic/Mechanical | ||||||
| 51 | Shift (Fwd/Rvs) | 1/1 (2/2) | |||||||
| 52 | Work pressure | Mpa | 17.5 | ||||||
Company Introduction
Shanghai Gather Power Industry Co.,Ltd (shanghai gather power), was registered in 2006 in Shanghai, China, a major industrial logistics equipment manufacturer and supplier of professional products, the main production and operation of three series of products: 1 t -2.5 t full electric stacker, 1 t -3 t full electric pallet trucks, 1 t -2.5 t Reach forklift and other electric storage equipment; 6 meters - 30 meters series of aerial work platforms; 25 tons -45 tons of container crane and so on.
Company has three bases: Shanghai Fengxian production base; Pudong Zone International Trade Company; Lu'an production base - Anhui Vmax Machinery Co., Ltd.
After nearly seven years of continuous development, the company has entered a rapid healthy development. The company has a total of over 40,000 square meters of production space, with a large number of such large-scale CNC flame plasma cutting machine, high-precision machining centers, CNC milling machine, large hydraulic machines, systems integrated coating equipment, as well as the international advanced assembly products performance test line, precision testing equipment, vehicle testing facilities to strengthen inspection and testing systems, which are fully guaranteed product standards and quality.
permarket, Sharp Electronics, China COSCO, Maersk Logistics and many other Fortune 500 companies.
