Reach Stacker Forklift

Reach Stacker Forklift thumbnail-1
Reach Stacker Forklift photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
GP
Contact Supplier Request Quote Chat Now
Shanghai Gather Power Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shanghai, China
Brand Name GP
Model Number ERD112-45
Type Powered Pallet Truck
Power Souce DC Motor
Rated Loading Capacity 1200KG
Max. Lifting Height 2500
Min. Lifting Height 0mm
Fork Length 1070mm
Fork Width 100
Overall Dimensions 35*100*1070mm

Specifications

1) Integrated handle make operation easy and comfortable
2) USA CURTIS DC Controller
3) Electromagnetic Brake
4) Long life

Integrated handle make operation easy and confortable


1) Integrated handle make operation easy and comfortable 2) USA CURTIS DC Controller 3) Electromagnetic Brake 4) Long life and hard-wearing PU wheel 5) Be suitable for working with lower storage shelves

Electric Reach Stacker Model
Specification Unit ERD112-16 ERD112-25 ERD112-33 ERD112-45 ERD115-16 ERD115-25 ERD115-33 ERD115-45
Power   battery
Load capacity (kg)   1200       1500
Lift height H1(mm) 1600 2500 3300 4500 1600 2500 3300 4500
Load centre Q(mm) 500
Fork carriage tilt(forward/backward) α/β(deg) 2/4
Travel speed (with/without load) (km/h) 4.5/5.5
Lifting speed (with/without load) (mm/s) 90/125
Max gradeability (with/without load) (%) 6/8
Wheel base Y(mm) 1350
Service brake   Electromagnetic
Overall length L(mm) 2260
Overall width (mm) 1100
Height of mast, lowered H2(mm) 1985 1785 2185 2140 1985 1785 2185 2140
Height of mast, extended H3(mm) 2235 3260 4060 5400 2235 3260 4060 5400
Free lift height h4(mm)   -   1530   -   1530
Reach distance X1(mm) 550
Fork dimensions (mm) 35×100×1070 40×100×1070
Min turning radius wa(mm) 1500
Service weight (kg) 1350 1480 1580 1780 1550 1680 1780 1980
Drive motor (kw)       1.5
Lift motor (kw)       3
Battery(5h) V/Ah 24/240
Tyres   PU
Size of front tyre mm 178 x 75
Size of rear tyre mm 230 x 76
Size of balancing tyre mm 156 x 75
Speed control system   USA CURTIS, Italia ZAPI, SME
