Home > Transportation > Forklifts & Parts > Forklift > Full Electric Reach Trucks Forklifts Worked in Narrow Aisles
Full Electric Reach Trucks Forklifts Worked in Narrow Aisles
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
GP
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Shanghai, China
Brand Name
GP
Model Number
ETV120-30
Type
Powered Pallet Truck
Power Souce
DC Motor
Rated Loading Capacity
2000
Max. Lifting Height
3000mm
Min. Lifting Height
0mm
Fork Length
1070mm
Fork Width
100mm
Specifications
1 ton full electric reach truck1.large and strong chassis
2.Germany steel mast
3.Large and comfortable compartment
1 ton full electric reach truck
| Electric Reach Truck | Model | |||||
| Item | Specification | Unit | ETV110-30 | ETV115-30 | ETV120-30 | |
| 1 | Characteristics | Power | Battery | Battery | Battery | |
| 2 | Operation | Seated | Seated | Seated | ||
| 3 | Load Capacity | Q(kg) | 1000 | 1500 | 2000 | |
| 4 | Lift height (biggest) | h3(mm) | 3000 | 3000 | 3000 | |
| 5 | Load Center | c(mm) | 500 | 500 | 500 | |
| 6 | Axle centre to fork face | x(mm) | 390 | 390 | 380 | |
| 7 | Wheelbase | Y(mm) | 1480 | 1480 | 1500 | |
| 8 | Weight | Service Weight | kg | 2200 | 2400 | 3300 |
| 9 | Wheel | Tyre | PU Wheel | PU Wheel | PU Wheel | |
| 10 | Tyre size, front | mm | ø280*100 | ø280*100 | ø406*152 | |
| 11 | Tyre size, rear | mm | ø250*80 | ø250*80 | ø340*104 | |
| 12 | Wheel, front/rear | 3.2 | 3.2 | 2.1 | ||
| 13 | Track width, front | b10(mm) | 740 | 740 | 835 | |
| 14 | Track width, rear | b11(mm) | 996 | 996 | 1012 | |
| 15 | Dimensions | Mast/fork carriage tilt,forwar/backward | α,β(Grad) | 2.5 | 2.5 | 2.2 |
| 16 | Height of mast lowered | h1(mm) | 2086 | 2086 | 2086 | |
| 17 | Free lift | h2(mm) | ~ | ~ | ~ | |
| 18 | Height of mast, extend | h4(mm) | 3800 | 3800 | 3800 | |
| 19 | Height of overhead guard (cabin) | h6(mm) | 2114 | 2114 | 2200 | |
| 20 | h7(mm) | 920 | 920 | 1068 | ||
| 21 | Height of reach legs | h8(mm) | 270 | 270 | 270 | |
| 22 | Length to fork face | l1(mm) | 2390 | 2390 | 2040 | |
| 23 | Overall length | l2(mm) | 1850 | 1850 | 2440 | |
| 24 | Overall width | b1(mm) | 1100 | 1100 | 1260 | |
| 25 | A,B Fork carriage to DIN 15173, class/form A,B | A | A | A | ||
| 26 | Fork carriage width | b3(mm) | 928 | 928 | 928 | |
| 27 | Fork spread | b5(mm) | 640 | 640 | 640 | |
| 28 | Width between reach legs | b4(mm) | 800 | 800 | 900 | |
| 29 | Reach travel | l4(mm) | 600 | 600 | 600 | |
| 30 | Ground clearance, mast | m1(mm) | 90 | 90 | 90 | |
| 31 | Ground clearance, center of wheelbase | m2(mm) | 80 | 80 | 80 | |
| 34 | Turning radius | Wa(mm) | 1740 | 1740 | 1820 | |
| 35 | Performance | Travel speed, with/without load | Km/h | 7/7.2 | 7/7.2 | 8/8.3 |
| 36 | Lifting speed, with/without load | m/s | 0.19/0.2 | 0.19/0.2 | 0.19/0.2 | |
| 37 | Lowering speed, with/without load | m/s | 0.5/0.4 | 0.5/0.4 | 0.5/0.4 | |
| 38 | Reach speed, with/without load | m/s | 0.1/0.1 | 0.1/0.1 | 0.1/0.1 | |
| 39 | Climbing ability, with/without load | % | 10/12 | 10/12 | 10/12 | |
| 40 | Acceleration time, with/without load | s | 3/4 | 3/5 | 4.8/4.3 | |
| 41 | Service brake | mechanical | mechanical | hydraulic | ||
