Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
GP
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Shanghai, China
Brand Name
GP
Model Number
ETM10
Type
Powered Pallet Truck
Power Souce
DC Motor
Rated Loading Capacity
1000kg
Max. Lifting Height
7200mm
Min. Lifting Height
3000mm
Fork Length
1070mm
Fork Width
100mm
Overall Dimensions
2115*1045*3915mm
Certification
ISO&CE
After-sales Service Provided
Overseas service center available
Specifications
1)Clear view fixed mast2)Large capacity Lifting Motor
3)German DIN STD battery
3)Safety design, reach ISO & CE
1) Clear view fixed mast
2) Diagnostics,via a CAN bus connection, enable rapid servicing and maximum uptime
1) Clear view fixed mast
2) Diagnostics,via a CAN bus connection, enable rapid servicing and maximum uptime
3) Maximum residual capacities at high lift
4) Large capacity Lifting Motor
5) Safety design, reach ISO & CE
2) Diagnostics,via a CAN bus connection, enable rapid servicing and maximum uptime
3) Maximum residual capacities at high lift
4) Large capacity Lifting Motor
5) Safety design, reach ISO & CE
| Electric Reach Truck | Model | |||||||
| Item | Specification | Unit | ETM10-30 | ETM13-30 | ETM15-30 | ETM18-30 | ETM20-30 | |
| 1 | Characteristics | Power | Battery | |||||
| 2 | Operation | Stand-on | Stand-on | Stand-on | Stand-on | Stand-on | ||
| 3 | Rated load capacity | Q(kg) | 1000 | 1300 | 1500 | 1800 | 2000 | |
| 4 | Rated lift height | h3(mm) | 3000 | |||||
| 5 | Load centre | C(mm) | 500 | |||||
| 6 | Fork carriage tilt (Forward/Backward) | α/β(Deg) | 3°/5° | |||||
| 7 | Travel speed (Laden/Unladed) | km/h | 8.0/8.5 | 8/8.5 | 8.8/9.3 | 8.5/9.3 | 9.1/9.0 | |
| 8 | Lifting speed(Laden) | mm/s | 175 | 175 | 240 | 230 | 220 | |
| 9 | Max. gradeability(Laden) | % | >12 | >12 | >12 | >12 | >10 | |
| 10 | Min. turning radius | Wa(mm) | 1420 | 1620 | 1725 | 1735 | 1775 | |
| 11 | Reach distance | X(mm) | 520 | 720 | 600 | 600 | 645 | |
| 12 | Wheelbase | Y(mm) | 1160 | 1360 | 1470 | 1470 | 1520 | |
| 13 | Service brake | Elec | Elec | Elec | Elec | Elec | ||
| 14 | Dimensions | Overall width | l1(mm) | 2115 | 2125 | 2340 | 2350 | 2350 |
| 15 | Main body length | l2(mm) | 1045 | 1055 | 1270 | 1280 | 1280 | |
| 16 | Overall width | b1(mm) | 1045 | 1045 | 1200 | 1216 | 1216 | |
| 17 | Height of mast, lowered | h1(mm) | 2080 | 2080 | 2085 | 2085 | 2085 | |
| 18 | Free lift height | h2(mm) | 330 | |||||
| 19 | Height of mast, extended | h4(mm) | 3915 | 3915 | 4000 | 4000 | 4000 | |
| 20 | Height of overhead guard | h5(mm) | 2210 | 2210 | 2260 | 2260 | 2260 | |
| 21 | Fork dimensions(TxWxL) | mm | 35x100x1070 | 35x100x1070 | 35x122x1070 | 40x122x1070 | 40x122x1070 | |
| 22 | Min. ground clearance | h6(mm) | 80 | |||||
| 23 | Aisle width with pallet (1200x1200) | Ast1(mm) | 2660 | 2710 | 2910 | 2920 | 2920 | |
| 24 | Aisle width with pallet (1000x1000) | Ast2(mm) | 2440 | 2495 | 2690 | 2700 | 2700 | |
| 25 | Weight | Service weight | kg | 2050 | 2150 | 2670 | 2700 | 2725 |
| 26 | Motor | Driven motor | Kw | 2.2 | 2.2 | 4.5 | 4.5 | 4.5 |
| 27 | Lift motor | Kw | 3.5 | 3.5 | 9.2 | 9.2 | 9.2 | |
| 28 | Battery: Voltage/capacity (5h)standard (option) | (V/Ah) | 48/210 *48/225 | 48/210 *48/225 | 48/420 *48/500 | 48/420 *48/500 | 48/420 *48/500 | |
| 29 | Wheel | Tyres | Polyurethane tyre | |||||
| 30 | Size of front tyre | mm | Φ250x70 | Φ250x70 | Φ250x120 | Φ250x120 | Φ250x120 | |
| 31 | Size of rear tyre | mm | Φ381x130 | |||||
| 32 | Size of balancing tyre | mm | Φ178x75 | |||||
| 33 | Track width(front) | mm | 975 | 975 | 1070 | 1070 | 1070 | |
| 34 | Track width(rear) | mm | 490 | 490 | 580 | 580 | 580 | |
| 35 | Turning system | Hydraulic | ||||||
| 36 | Speed control system | ZAPI / Curtis | ||||||
