Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
GP
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Shanghai, China
Brand Name
GP
Model Number
CPD15J
Type
Powered Pallet Truck
Power Souce
AC Motor
Rated Loading Capacity
1500kg
Max. Lifting Height
3000mm
Min. Lifting Height
0mm
Fork Length
920mm
Fork Width
100mm
Overall Dimensions
2056*1090*2162mm
Specifications
AC powered, 4 wheel options1.5/2/2.5/3/3 tons
Imported Electronic Control, Seal & Bearing
CE, ISO audit Manufaturer
Technical Specifications:
| Characteristics | ||||||||
| 1 | 4-wheel AC Power Pneumatic Tire Electric Forklift | CPD20 | CPD25 | CPD30 | CPD35 | |||
| 2 | Capacity | at rated load center | kg | 1500 | 2000 | 2500 | 3000 | |
| at load center - distance | mm | 500 | ||||||
| 3 | Power | diesel, Gasoline / LPG, electric | electric | |||||
| 4 | Tire Type | solid, pneumatic | pneumatic | |||||
| 5 | Wheels (x = drive) | number front / rear | 2x/2 | |||||
| Dimensions | ||||||||
| 6 | Lift Height with standard two-stage mast (VM) | mm | 3000 | |||||
| 7 | Free Lift Height | mm | 2x/2 | 140 | 140 | 145 | ||
| 8 | Fork size | Length*Width*Thickness | mm | 920x100x40 | 1070x120x40 | 1070x120x45 | 1070x125x45 | |
| 9 | Fork spacing (Min./Max.) | out-to-out | mm | 200/968 | 240/1040 | 240/1040 | 250/1100 | |
| 10 | Mast tilt angle | Forward / Backward | deg | 6/12 | 6/10 | 6/10 | 6/10 | |
| 11 | Overall dimensions | length (to fork face) | mm | 2056 | 2349 | 2381 | 2481 | |
| width (standard) | mm | 1090 | 1265 | 1265 | 1265 | |||
| height | with lowered mast | mm | 1995 | 2040 | 2040 | 2040 | ||
| with extended mast | mm | 4042 | 4240 | 4240 | 4273 | |||
| to top of overhead guard | mm | 2162 | 2125 | 2125 | 2125 | |||
| 12 | Turning radius (outside) | mm | 1820 | 2050 | 2100 | 2230 | ||
| 13 | Load distance (centerline of front axle to front face of forks) | mm | 429 | 459 | 464 | 454 | ||
| Performance | ||||||||
| 14 | Speeds | Travel speed | loaded | km/h | 13 | 12 | 12 | 12 |
| 15 | empty | km/h | 15 | 14 | 14 | 14.5 | ||
| 16 | Lifting speed | loaded | mm/sec | 300 | 310 | 300 | 280 | |
| 17 | empty | mm/sec | 400 | 420 | 420 | 420 | ||
| 18 | Gradeability | loaded/empty | % | 15 | 10 | 10 | 10 | |
| Weight | ||||||||
| 19 | empty | with minimum weight battery | Kg | 3120 | 4160 | 4360 | 4850 | |
| Chassis | ||||||||
| 20 | Tyre Size | Front, standard pnuematic tires | 6.5-10-10PR | 23x9-10-16PR | 23x9-10-16PR | 23x9-10 | ||
| 21 | Rear, standard pnuematic tires | 5.00-8-8PR | 18x7-8-14PR | 18x7-8-14PR | 18x7-8 | |||
| 22 | Wheel base | mm | 1250 | 1500 | 1500 | 1630 | ||
| 23 | Tread width | Front | mm | 890 | 1040 | 1040 | 1040 | |
| Rear | mm | 920 | 950 | 950 | 980 | |||
| 24 | Min. Under-clearance (full load / no load ) | at lowest point at mast | mm | 95/110 | 85/105 | 85/105 | 85/105 | |
| 25 | at center of wheelbase | mm | 95/105 | 120/140 | 120/140 | 120/140 | ||
| Powertrain | ||||||||
| 26 | Battery | Voltage | V | 48 | 48 | 48 | 80 | |
| 27 | Capacity | AH | 400/440/480 | 630/700 | 630/700 | 500/600 | ||
| 28 | Electric motor | Drive motor output | kw/rpm | 8/1600 | 8/1300 | 8/1300 | 13/1500 | |
| 29 | Hydraulic motor output | kw/rpm | 10/2450 | 15/2200 | 15/2200 | 22/2100 | ||
| 30 | controller | Italian SME AC controller | ||||||
