Home > Products > Container Crane > 30T to 40T Mast Mobile Container Crane
30T to 40T Mast Mobile Container Crane
USD $15,000 - $30,000
/ Unit
1 Unit(Min.Order)
- 500 Unit / Units per Month
- Shanghai
- T/T Credit Card
You May Like
- Stable performance computer Board Recycling Machine
- Lithium Ion Battery Recycling Machine For Black Mass And Metal
- Cement dry ash bulk machine telescopic ring cloth bag DN300/600 thickened wear-resistant
- Homogenization tank B200 external fluidization plate homogenization tank inflation equipment
- B400 Electro-hydraulic sector valve Pneumatic sector valve Block material sector valve can be customized
- Bulk material bulk hangar bottom cement clinker sand aggregate loading inside the wear-resistant ceramics
Product Details
Place of Origin: | Shanghai, China | Brand Name: | GP | Model Number: | BSJD300-360, 400 |
After-sales Service Provided: | Overseas third-party support available |
Product Description
Specifications
Mast Mobile Container Crane ,INCLUDE 30T,36T,40TBSJD300T- BSJD400T mast mobile container crane is specially designed for small and medium size freight yard, her advantage is the lowest operating cost among all kinds of container cranes. This equipment is powered with multi-cylinder diesel engine, with good features of low noise and low vibration. Lifting and walking are both controlled by hydraulic system, driving by hydraulic motor. Diameter of lifting cylinder is 200mm, the more the loading capacity, the smaller the pressure of lifting system, it is absolutely steady and safe when lifting and declining, and with high efficiency of loading or unloading. Each equipment is composed of two cranes, each crane is an independent motor unit, each motor unit is two-wheel driving(2WD), four-wheel steering(4WD), the max. turning angle is 90 degrees, can steer and shift at any angle. With small turning radius, it can be operated flexiblely. And the two motor units both can move freely, the space between also can be adjusted at will, it can be used for lifting various containers. This equipment should be used on flat, hardening and no pothole container yards. It is applicable to load or unload for logistics companies, warehouses, piers, container yards, freight yards, etc. It is a super quality and competitive price, convenient and practical container lifting equipment.
specification | ||||||
1 | model number | BSJD300 | BSJD360 | BSJD400 | ||
2 | Total weight | Ton | 7 | 7.5 | 8 | |
3 | rated capacity | Kg | 30000 | 36000 | 40000 | |
4 | max.Steering speed (without load) | Km/h | 3.5 | 3.5 | 3.5 | |
5 | Min.Passageway width | mm | 3200 | 3200 | 3200 | |
6 | rated torque of hydraulic | Nm | 1010 | 1010 | 1010 | |
7 | Max. Lifting speed | with load | mm/s | 30 | 30 | 30 |
8 | without load | mm/s | 35 | 35 | 35 | |
9 | Max.falling speed | with load | mm/s | 25 | 25 | 25 |
10 | without load | mm/s | 25 | 25 | 25 | |
11 | engine power | Kw | 22 | 22 | 22 | |
12 | systerm pressure | Mpa | 13 | 15 | 16 | |
13 | rotation angle of turning wheel | O | 110 | 110 | 110 | |
specification of structure | ||||||
14 | L*W*H | mm | 5055*2655*6320 | |||
15 | Max height of lifting beam | mm | 4660 | 4660 | 4660 | |
16 | Lowest height of lifting beam | mm | 2270 | 2270 | 2270 | |
17 | Min Under-clearance | mm | 110 | 110 | 110 | |
18 | Lengthways tread | mm | 2205 | 2205 | 2205 | |
19 | Crosswise tread | mm | 3725 | 3725 | 3725 | |
20 | Inside width of crosswise | mm | 3275/3380 | 3275/3380 | 3275/3380 | |
specifications of engine | ||||||
SHANGHAI XINJIANG BRAND ENGINE model is B490G |
