36t mobile container crane tilting up to 40 degree
- 2000 Unit / Units per Month
- any port in China
- T/T Credit Card PayPal
- Lvrui machinery powder ash special air chute sealing good no noise wide range of application
- Lvrui mechanical fly ash cement XZ630 chute wide application range solid and durable
- Cement mineral powder dry ash raw material CP400 electro-pneumatic flow control valve Green Rui machinery
- Aeration box Homogenization warehouse aeration equipment customized according to a variety of specifications
- Stable performance computer Board Recycling Machine
- Lithium Ion Battery Recycling Machine For Black Mass And Metal
Product Details
Place of Origin: | Shanghai, China | Brand Name: | GP | Model Number: | BSJD360 |
Product Description
Specifications
le container crane2.CE and ISO certificate
BSJD300T- BSJD400T mast mobile container crane is specially designed for small and medium size freight yard, her advantage is the lowest operating cost among all kinds of container cranes. This equipment is powered with multi-cylinder diesel engine, with good features of low noise and low vibration. Lifting and walking are both controlled by hydraulic system, driving by hydraulic motor. Diameter of lifting cylinder is 200mm, the more the loading capacity, the smaller the pressure of lifting system, it is absolutely steady and safe when lifting and declining, and with high efficiency of loading or unloading. Each equipment is composed of two cranes, each crane is an independent motor unit, each motor unit is two-wheel driving(2WD), four-wheel steering(4WD), the max. turning angle is 90 degrees, can steer and shift at any angle. With small turning radius, it can be operated flexiblely. And the two motor units both can move freely, the space between also can be adjusted at will, it can be used for lifting various containers. It is applicable to load or unload for logistics companies, warehouses, piers, container yards, freight yards, etc. It is a super quality and competitive price, convenient and practical container lifting equipment.
MAST MOBILE CONTAINER CRANE | ||||||
specification | ||||||
1 | model number | BSJD300 | BSJD360 | BSJD400 | ||
2 | Total weight | Ton | 7 | 7.5 | 8 | |
3 | rated capacity | Kg | 30000 | 36000 | 40000 | |
4 | max.Steering speed (without load) | Km/h | 3.5 | 3.5 | 3.5 | |
5 | Min.Passageway width | mm | 3200 | 3200 | 3200 | |
6 | rated torque of hydraulic | Nm | 1010 | 1010 | 1010 | |
7 | Max. Lifting speed | with load | mm/s | 30 | 30 | 30 |
8 | without load | mm/s | 35 | 35 | 35 | |
9 | Max.falling speed | with load | mm/s | 25 | 25 | 25 |
10 | without load | mm/s | 25 | 25 | 25 | |
11 | engine power | Kw | 22 | 22 | 22 | |
12 | systerm pressure | Mpa | 13 | 15 | 16 | |
13 | rotation angle of turning wheel | O | 110 | 110 | 110 | |
specification of structure and engine | ||||||
14 | L*W*H | mm | 5055*2655*6320 | |||
15 | Max height of lifting beam | mm | 4660 | 4660 | 4660 | |
16 | Lowest height of lifting beam | mm | 2270 | 2270 | 2270 | |
17 | Min Under-clearance | mm | 110 | 110 | 110 | |
18 | Lengthways tread | mm | 2205 | 2205 | 2205 | |
19 | Crosswise tread | mm | 3725 | 3725 | 3725 | |
20 | Inside width of crosswise | mm | 3275/3380 | 3275/3380 | 3275/3380 | |
21 | engine | Xinchang 490 |
