Lifting Height 20m Telescopic Boom Lift

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

Model Number:

GTBZ20/22

Shanghai Gather Power Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name GP

Model Number GTBZ20/22

Max Lifting Height 20/22m

Specifications

Configuration for auto-control, against dangersfromcrashing,overload,tip-over,ect.
Dual-sensor adopted for necessary length

Item	Measurement	Item	Measurement
Dimensions		Productivity
Overall length(stowed)	9.18M (30ft)	Platform height max.	20.6M (68ft)
Overall width(stowed)	2.49M (8ft)	Working height max.	22.6M (74ft)
Overall height(stowed)	2.8M (9ft)	Horizontal reach max.	17.3M (57ft)
Ground clearance	0.31M (1ft)	Turntable rotation	360°continuous
Wheelbase	2.49M (8.2ft)	Platform rotation	160°
Overall weight	11015kg (2WD)	Platform Load capacity	250kg (non-restricted)
Overall weight	11085kg (4WD)	Platform Load capacity	340kg (restricted)
Platform Size (LWH)	1.830.761.1M(6ft 2.5ft 3.6ft)	Grade ability	40% (2WD)
Platform Size (LWH)	1.830.761.1M(6ft 2.5ft 3.6ft)	Grade ability	45% (4WD)
Platform levelling	Automatic	Turning radius(outside)	4.97M (16.3ft)
Tire specification	9.00-20	Turning radius(inside)	1.66 M (5.5ft)
Tire type	Solid	Turntable tailswing	1.32M (4.3ft)
Power		Max. Driving Speed	6.3km/h
Hydraulic tank vol.	170L	Driving Speed (stowed)	0~6.3km/h
Hydraulic system vol. (inc. the tank)	270L	Driving Speed (extended)	0~1.1km/h
Fuel tank vol.	125L	Max allowable wind force	12.5m/s
Control voltage	24V	Max allowable slope	3°
Engine	Original CumminsB3.3 60hp	Max noiseon normal use	82dB(A)
Drive & steer model	2WD*2WS	Max allowable side force	400N
