Lifting Height 15m Ariticualting Boom

Shanghai Gather Power Industry Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

Model Number:

GTZZ15

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name GP

Model Number GTZZ15

Specifications

Platform height max. 14.8M
Working height max. 16.8M
Horizontal reach max. 7.62M
PlatformLoad capacity250kg

ariticualting boom

Item	Measurement	Item	Measurement
Dimensions		Productivity
Overall length(stowed)	5.56M (18ft)	Platform height max.	14.8M (49ft)
Overall width(stowed)	2.1M (6ft)	Working height max.	16.8M (55ft)
Overall height(stowed)	2.18M (7ft)	Horizontal reach max.	7.62M (25ft)
Ground clearance	0.23M (0.8ft)	Turntable rotation	355°
Wheelbase	2.2M (7.2ft)	Platform rotation	160°
Overall weight	6500kg (2WD)	Platform Load capacity	250kg
Overall weight	7700kg (4WD)	Platform Load capacity	250kg
Platform Size (LWH)	1.830.761.1M (6ft 2.5ft 3.6ft)	Grade ability	40% (2WD)
Platform Size (LWH)	1.830.761.1M (6ft 2.5ft 3.6ft)	Grade ability	40% (4WD)
Platform levelling	Automatic	Turning radius(outside)	4.5M (15ft)
Tire specification	300-15	Turning radius(inside)	1.8 M (6ft)
Tire type	Solid	Turntable tailswing	0M (0ft)
Power		Max. Driving Speed	7km/h
Hydraulic tank vol.	70L	Driving Speed (stowed)	0~7km/h
Hydraulic system vol. (inc. the tank)	110L	Driving Speed (extended)	0~1.1km/h
Fuel tank vol.	135L	Max allowable wind force	12.5m/s
Control voltage	12V	Max allowable slope	3°
Engine	Perkins 404D-22T	Max noise on normal use	82dB(A)
Drive & steer model	2WD*2WS	Max allowable side force	400N
