Help CenterFactory Price 5T Electric Tow Tractor for Textile
Related Products
-
Cheap 3T Electric Tow TractorUS$ 4,000 - 6,000MOQ: 1 Set -
Jeakue Brand New Tractor Truck AC Seated 1.2T Electric Farm TractorUS$ 3,988 - 6,573MOQ: 1 Set
-
1800kg Paper Roller Long for Pallet Truck CEUS$ 700 - 700MOQ: 1 Set
-
CE Hand Pallet Truck 1500kg Paper Roller HandlingUS$ 650 - 650MOQ: 1 Set
-
2017 2000kg Double Lift Full Electric Pallet TruckUS$ 2,000 - 4,000MOQ: 1 Set
Brief introduction
Item No. | JK8180 | ||
Charactiristics | Electric source |
| Electric |
Operation type |
| Walking type | |
Lifting rated loading weight | Kg | ≤2000 | |
Drag and drop rated loading weight | Kg | ≤5000 | |
Rated loading wewight of pull rob on hook | kg | 97.6 | |
Focal distance | mm | 112 | |
Wheel base(y) | mm | 999 | |
Weight (excluding battery) | kg | 435 | |
Wheels | Tyre |
| polyurethane |
Driving end of wheel | mm | Φ230x75 | |
Loading end of wheel | mm | Φ150x60 | |
Size of balance wheel | mm | Φ100x50 | |
Qty of wheel (x= driving wheel), driving end/loading end |
| 1x-2/2 | |
Surface width of the driving end | mm | 400 | |
Surface width of the loading end | mm | 568 | |
Size | Whole height | mm | 1400 |
Lifting height | mm | 378 | |
Handle height at the driving position (max/min) | mm | 1350/800 | |
Whole height | mm | 1227 | |
Length to pallet fork | mm | 565 | |
Whole width | mm | 850 | |
Min ground clearance | mm | 70 | |
Turning radius | mm | 1200 | |
Performance | Running speed(full load/no load) | Kw/h | 5.2/6 |
Lifting speed(full load/no load) | mm/s | 40/50 | |
Declining speed(full load/no load) | mm/s | 50/40 | |
Max gradeability(full load/no load) | % | 8/15 | |
Service brake |
| Electromagnetic type | |
Driving | Driving motor watt | kw | 1.1 |
Lifting motor watt | kw | 2.2 | |
Battery, voltage/capacitance | V/Ah | 24/210 | |
Weight of battery | kg | 195 | |
Shenchuan (Shanghai) Heavy Industrial Machinery Co., Ltd. was established in May 2003 in Shanghai. Over the past 10 years, we have been always adhering to the idea of “all service to meet customers’ needs”, breaking through technology, manufacturing the finest products, improving service with our globalization vision.
We have developed a variety of international advanced products joint with world-renowned industrial equipment manufacturers, such as: ABB, ZF, BOSCH, CAT, TEREX, and a variety of sophisticated products with independent intellectual property patents together with well-known Chinese universities in the area of machinery, electronics, physical mechanics etc.
We will provide comprehensive and multidimensional supply chain service for global customers with our most optimized scheme, best quality products, most attentive service and most competitive price, to reduce the maximum supply chain cost for customers and increase the production efficiency.
—————————————————————————————————————————————————
