Huatong Brand Asphalt Concrete Tyre Paver 9m Paving Width (SPS90C)

Huatong Brand Asphalt Concrete Tyre Paver 9m Paving Width (SPS90C) photo-1
US$ 1 - 180,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Production Capacity:
140kw
Power(W):
140kw
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Production Capacity 140kw
Power(W) 140kw
Max. Paving Thickness 320mm
Paving Width 9000m
Place of Origin Jiangsu, China
Brand Name huatong
Model Number SPS90C
Dimension(L*W*H) 9000x320x700
Weight 21-27tons
Certification ISO9001
Warranty 1year
After-sales Service Provided Overseas third-party support available

Huatong brand Asphalt Concrete Tyre Paver 9m paving width (SPS90C)



•Suitable for paving road base and road surface;
•Adopt advanced technology, high automation, user-friendly and high efficiency;
• Track travelling device: the tracks of both sides are driven independently and hydraulically, and controlled by micro-computer;
•Conveyor system: the left and right conveyors adopt the ultrasonic material level sensor to feed the material evenly.
•Automatic leveling sensors: the machine is equipped with two longitudinal and one transverse automatic leveling probe, which reaches the demand of high-grade road smoothness.
•Centralized lubricating system: the system presses the lubricant into all bearings with high temperature to improve the reliability of the machine;
•Advanced screed: screed has vibration and tamper to offer quality of pre-pressed compaction. The mechanically extended screed could pave the road surface of different width.
•Parts: précised and digital compensating beam leveling device and multiple types of screed could meet the requirement of different users and work conditions.



Name

Unit

Parameter

Name

Unit

Parameter

Max. paving width

mm

9000

Basic width

mm

3000

Max. paving thickness

mm

320

Vibrator amplitude

mm

Main:5,Auxiliary:0,3,6,9,12

theoretical output

t/h

700

Vibrator strike times

time/min

0-1500

Paving speed

m/min

0-19

Screed vibrator frequency

Hz

0-50

Travel speed

km/h

0-2.9

Screed heating method



Gas heating

Driving manner



Hydraulic

Fuel tank capacity

L

345

Overall weight

t

21-27

Hydraulic oil tank capacity

L

320

Engine model and power



D6114ZG1BShangchai,140KW

Displayer



AT3Graph displayer from Germany

Track shoe width

mm

320

Controller



PLC2038 Finland

Hopper capacity

t

14

Centralized lubrication



Import

Automatic leveling



Made in China (assembled with imported parts)

Drop-off preventive device



with

Screw diameter

mm

400

Material level instrument



TYP Series Made in China

Screed extension



Mechanical
