Crawler Crane for Sale ZOOMLION QUY130 Crawler Crane Price

Name: Crawler Crane for Sale ZOOMLION QUY130 Crawler Crane Price
Brand: Zoomlion
SKU: 140721248
Availability: InStock

US$ 410,000 - 510,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Construction

Rated Loading Capacity:

130t

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Construction

Rated Loading Capacity 130t

Rated Lifting Moment 661.5t.m

Max. Lifting Load 130t

Max. Lifting Height 80m

Span 19-73m

Place of Origin Hunan, China

Brand Name Zoomlion

Model Number QUY130

Certification CE/ISO9001

Warranty 12 Months

After-sales Service Provided Engineers available to service machinery overseas

Crawler crane for sale ZOOMLION QUY130 crawler crane price

whatsApp/Tel:+86 18217056032

Ser. No.	Item	Unit	Value	Remark
1	Maximum lifting weight ×radius	t×m	130×4.5
2	Maximum lifting moment	T·m	661.5	94.5 (lifting weight) × 7 (range)
3	Basic boom dead weight	t	113.8
4	Length of main boom	m	19~73
5	Length of fixed jib	m	13~31
6	Maximum lifting weight of fixed jib	t	13
7	Fixed jib installation angle	°	10,30
8	Maximum length of main boom + fixed jib	m	55+31,58+25,61+19
9	Speed of rope on the drum of main winch	m/min	105	Drum outermost layer
10	Speed of rope on the drum of auxiliary winch	m/min	93	Drum outermost layer
11	Speed of rope on the drum of derricking winch	m/min	52	Drum outermost layer
12	Swing speed	r/min	0~2.2
13	Travelling speed	km/h	0~1.3
14	Gradeability	%	30%
15	Pressure to the ground	MPa	0.1
16	Outline dimension length ×width ×height	m	9.55×6.5×3.2	Mast-free main boom
17	Engine rated power / speed	Kw/rpm	209/2000
18	Engine maximum output torque / speed	N·m/rpm	1424/1500
19	Engine emission standard		U. S. EPA Tier Ⅲ
