Zoomlion QUY400 400ton Crawler Crane Quy 200 Zoomlion Crawler Crane

Name: Zoomlion QUY400 400ton Crawler Crane Quy 200 Zoomlion Crawler Crane
Brand: Zoomlion
SKU: 140721256
Availability: InStock

US$ 150,000 - 242,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Construction

Rated Loading Capacity:

400T

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Construction

Rated Loading Capacity 400T

Max. Lifting Load 400T

Max. Lifting Height 89m

Brand Name Zoomlion

Model Number QUY400

Certification ISO9001

Warranty 1 Year

After-sales Service Provided Engineers available to service machinery overseas

Zoomlion QUY400 400ton crawler crane quy 200 zoomlion crawler crane

whatsApp/Tel:+86 18217056032

Item			Value	Remarks
Max. lifting capacity /Radius		Without superlift counterweight t×m	400×6
		With superlift counterweight t×m	400×8
Main boom length m			24~84
Length of main boom with light boom head		Without superlift counterweight m	48~102
		With superlift counterweight m	78~126
Deadweight with basic boom t			350
Fixed jib length m			12~36
Max. lifting capacity of fixed jib t			80
Offset angle of Fixed jib°°			10,30
Max. length of main boom with fixed jib	Without superlift counterweight m		72+36
	With superlift counterweight m		84+36
Luffing jib length	Without superlift counterweight m		24~66
	With superlift counterweight m		24~84
Max. lifting capacity of luffing jib	Without superlift counterweight m		140
	With superlift counterweight m		180
Main boom angle under luffing jib working condition °			65,75,85
Max. length of main boom with luffing jib	Without superlift counterweight m		54+66
	With superlift counterweight m		84+84
Max. speed of single rope on drum	Main winchm/min		0~140
	Auxiliary winchm/min		0~140
	Derricking winchm/min		2×0~60
	Luffing winchm/min		0~125
	Superlift derricking winch m/min		0~146
