Wecan 3ton Diesel Forklift For Sale

Name: Wecan 3ton Diesel Forklift For Sale
Brand: Wecan
SKU: 140720894
Availability: InStock

US$ 1 - 10 MOQ: 1 Unit

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

Wecan

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai port or Qingdao port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name Wecan

Model Number CPCD30FR

Type Powered Pallet Truck

Power Souce Diesel Engine

Rated Loading Capacity 3ton

Max. Lifting Height 3000mm

Min. Lifting Height 45mm

Fork Length 1220mm

Fork Width 125mm

Overall Dimensions 3810*1230*2230 mm

Certification ISO9001,CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Wecan 3 ton Diesel Forklift For Sale
1) 2-stage 3000mm mast
2) warning light
3) powerful enigine
4)Hydraulic transmission

Wecan 3ton Diesel Forklift For Sale

3 ton Wecan Diesel Forklift CPCD30FR
1) 2-stage 3000mm mast
2) warning light
3) powerful enigine
4)Hydraulic transmission

3 ton Wecan Diesel Forklift CPCD30FR

Specifications of WECAN 3t diesel forklift:

MODEL		CPCD30FR
Load capacity		3000 kg
Load center		500 mm
Power type		Diesel
Max. lifting speeds(with load)		400mm/s
Max. driving speeds(with/without load)		18/20km/h
Max towering (with load)		15.5/10.5kn
Grade ability (with load)		15/20 %
Lifting height (H₁)		3000mm
Free lift		80 mm
Tilting angles(forward α-backward β)		6°/12°
Min. turning radius		2500mm
Min. Right angle aisle width		2110mm
Min. under-clearance		135mm
Dimensions	Overall length(including fork) (A)	3800 mm
	Overall width (B)	1230mm
	Overall height(mast lowered) (H)	2110 mm
	Overall height(mast extended) (H₂)	4270mm
Overall height to overhead guard (H₃)		2110mm
Fork overhang (A₁)		465mm
Wheel base(A₂)		1700 mm
Tread	Front tread(B₁)	1000 mm
	Rear tread (B₂)	970mm
Tire	Front tire	28×9-15
	Rear tire	6.50-10
Total weight		4320kg
Fork width(B₃)		125 mm
Fork thickness(H₄)		45 mm
Backrest height		1225 mm
Fork length (A₃)		1220mm
Engine	Engine model	490
	Rated power	39 kw
	Rotate speed at rated power	2650rpm
	Max. Torque	157 nm
	Rotate speed at max. Torque	1980 rpm
Type of power shift		Tor-con
Packing details	2PCS/20’CNT; 6PCS/40’CNT
