SHANTUI 320HP Used Cheap Bulldozer SD32

Name: SHANTUI 320HP Used Cheap Bulldozer SD32
Brand: SHANTUI
SKU: 140720404
Availability: InStock

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

US$ 100,000 - 350,000 MOQ: 1 Unit

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

SHANTUI

Model Number:

SD32

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI QINGDAO TIANJIN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name SHANTUI

Model Number SD32

Condition New

Moving Type Crawler Bulldozer

Machine Weight 37.2ton

Dimension(Long * Breadth * High) 6880*4130*3725mm

After-sales Service Provided Engineers available to service machinery overseas

SHANTUI 320HP used cheap bulldozer SD32

Product Description

Parameter

ITEM	UNIT	SD32D
L×W×H (Ripper not included)	mm	6880×4130×3725
Operating weight (Ripper not included)	t	37.2
Engine	-	NTA855-C360S10
Rated power	kW/rpm	235/2000
Gradeability	°	30
Blade type	-	Straight tilt bladeSemi-U bladeAngle blade
Blade width	mm	Straight tilt blade 4130×1590Semi-U blade4030×1720Angle blade 5000×1140
Dozing capacity	m3	Straight tilt blade 10Semi-U blade 11.9Angle blade 6
Ma× drop below ground of blade	mm	560
Lift height of blade	mm	1560
Ripper type	-	Single ripperThree-shank ripper
Ripping depth of ripper	mm	Single ripper 1250Three-shank ripper 842
Lifting height of ripper	mm	Single ripper 955Three-shank ripper 883
Number of carriers (each side)	-	2
Number of track rollers (each side)	-	7
Number of track shoes (each side)	-	41
Width of track shoe	mm	760
Track gauge	mm	2140
Ground length and ground pressure	mm/MPa	3150-0.076
Pitch	mm	228.6
Forward speed	km/h	0–3.6
		0–6.6
		0–11.5
Reverse speed	km/h	0–4.4
		0–7.8
		0–13.5
