SHANTUI 420HP Types of Bulldozer SD42-3 Blade Capacity 16M3

Name: SHANTUI 420HP Types of Bulldozer SD42-3 Blade Capacity 16M3
Brand: SHANTUI
SKU: 140720384
Availability: InStock

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

US$ 300,000 - 500,000 MOQ: 1 Unit

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

SHANTUI

Model Number:

SD42-3

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI QINGDAO TIANJIN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name SHANTUI

Model Number SD42-3

Condition New

Moving Type Crawler Bulldozer

Machine Weight 53ton

Dimension(Long * Breadth * High) 9630*4315*3955mm

After-sales Service Provided Engineers available to service machinery overseas

SHANTUI 420HP types of bulldozer SD42-3 Blade Capacity 16M3

Product Description

ITEM	UNIT	SD42-3
L×W×H (Ripper not included)	mm	9630×4315×3955 (Ripper included)
Operating weight (Ripper not included)	t	53 (Ripper included)
Engine	-	KTA19-C525
Rated power	kW/rpm	310/2000
Gradeability	°	30
Blade type	-	Semi-U blade
Blade width	mm	4315×1875
Dozing capacity	m3	16
Max drop below ground of blade	mm	700
Lift height of blade	mm	1545
Ripper type	-	Single ripper
Ripping depth of ripper	mm	1400
Lifting height of ripper	mm	1130
Number of carriers (each side)	-	2
Number of track rollers (each side)	-	7
Number of track shoes (each side)	-	41
Width of track shoe	mm	610
Track gauge	mm	2260
Ground length and ground pressure	mm/MPa	3560-0.123
Pitch	mm	260.35
Forward speed	km/h	0–3.7
		0–6.8
		0–12.2
Reverse speed	km/h	0–4.4
		0–8.2
		0–14.8
