Specifications
KaiFan Middle Duty Road Wrecker1.HOWO chassis
2.Rated towing weight: 32000kg
3.Max lifting weight: 12435kg
KFM5322TQZ08H Road wrecker is used for safety salvage of vehicles subject to city road, suburb way, highway, airport and bridge road. It is suitable for medium and small-sized cargos, cars and other special vehicles, which are allowed within the technical parameters of this kind.
Item | Unit | Value |
Lifting weight | kg | 7500 |
Max. Lifting weight | kg | 12435 |
Max. Lifting weight of original place | g | 14000 |
Max. Lifting weight of full extension boom | kg | 4000 |
Rated towing weight | kg | 32000 |
Max. Designed towing weight | kg | 60000 |
Effective length of boom | mm | 3415 |
Extension traveling of boom | mm | 1700 |
Folding angle of boom | ° | 90 |
Max. Rated hanging weight | kg | 14000 |
The height from hook to the ground | mm | 9430 |
Extension traveling of lifting boom | mm | 3045 |
Turning angle | ° | 360 |
Numbers of winch | piece | 2 |
Rated pulling power of winch | kg | 10000×2 |
Dia. Of steel cable | mm | 18 |
Length of steel cable | m | 40 |
Min. Speed of steel cable | m/min | 7 |
Rotation angle | ° | 54 |
External dimension | mm | 10410×2500×3185 |
Chassis model |
| ZZ1257M5847C |
Drive |
| 6×4 |
Axle base | mm | 5825+1350 |
The whole weight of empty load | kg | 19435 |
Load of front axle of empty load | kg | 7205 |
Load of rear axle of empty load | kg | 12230 |
The whole weight of full load | kg | 32000 |
Load of front axle of full load | kg | 7000 |
Load of rear axle of full load | kg | 25000= |
Wheel base (front/rear axle) | mm | 2022/1830 |
Front suspension | mm | 1500 |
Rear suspension | mm | 1205 |
Approach angle | º | 16 |
Departure angle | º | 23 |
Min. Ground clearance | mm | 260 |
Min. Turning diameter | m | ≤24 |
Grade ability | % | ≥30 |
Max. Speed | km/h | 90 |
Engine model | - | WD615.93E |
Engine emission | L | 9.726 |
Rated power | kw/r/min | 247/2200 |
Max. Torque | n·m/r/min | 1350/1100~1600 |
