Help CenterFlatbed Road Wrecker KFM5084TQZ06P
Related Products
-
Light-duty Road Wrecker Tow Trucks KFM5072TQZ For SaleUS$ 30,000 - 40,000MOQ: 1 Unit -
16m China Top Brand N.TRAFFIC Aerial Working PlatformNegotiableMOQ: 1 Set
-
High Quality Lower Price N.TRAFFIC 16M Aerial Working PlatformNegotiableMOQ: 1 Set
-
16M N.TRAFFIC Brand New Aerial Working Platform for SaleNegotiableMOQ: 1 Set
-
N.TRAFFIC Hot Sale 16M Telescopic Aerial Working PlatformNegotiableMOQ: 1 Set
Specifications
KaiFan Medium Duty Road Wrecker1.Jiefang chassis
2.Rated towing weight: 8400kg
3.Max lifting weight: 1500kg
KFM5084TQZ06P Road wrecker is used for safety salvage of vehicles subject to city road, suburb way, highway, airport and bridge road. It is suitable for medium and small-sized cargos, cars and other special vehicles, which are allowed within the technical parameters of this kind.
Items |
Unit |
Value |
|
Boom Structure |
Rated towing weight |
kg |
8400 |
Max. Lifting weight |
kg |
1500 |
|
Max. Lifting weight of full extending boom |
kg |
800 |
|
Effective length of boom |
mm |
1788 |
|
Extension traveling of boom |
mm |
1200 |
|
Elevation of boom (upper/ lower) |
7-10 |
||
Platform Structure |
Min. Elevation of full extending platform |
11 |
|
Max. Loading of platform |
kg |
3000 |
|
External dimension of platform (length×width×height) |
mm |
6150*2200*57 |
|
Ground clearance of cage floor |
mm |
1157 |
|
Max. Pulling power of winch |
kg |
4000 |
|
Dia. Of steel cable |
mm |
10 |
|
Length of steel cable |
m |
25 |
|
Min. Speed of steel cable |
m/min |
4.5 |
|
|
Vehicle Parameters |
External dimension |
mm |
9047*2280*2775 |
Chassis model |
CA5083XXYP9K2L4E |
||
Drive |
4*2 |
||
Axle base |
mm |
4800 |
|
The whole weight of empty load |
kg |
5665 |
|
Load of front axle of empty load |
kg |
2525 |
|
Load of rear axle of empty load |
kg |
3140 |
|
The whole weight of full load |
kg |
8495 |
|
Load of front axle of full load |
kg |
2995 |
|
Load of rear axle of full load |
kg |
5500 |
|
Wheel base (front/rear axle) |
mm |
1810/1740 |
|
Front suspension |
mm |
1330 |
|
Rear suspension |
mm |
2480 |
|
Approach angle |
18 |
||
Departure angle |
13 |
||
Max. Speed |
km/h |
99 |
|
Max. Grade ability |
>=32 |
||
Min. Turning diameter |
m |
<=19 |
|
Min. Ground clearance |
mm |
215 |
|
Engine model |
- |
CA4DF3-13E3 |
|
Engine emission |
ml |
4750 |
|
Rated power |
kw/r/min |
96/2500 |
|
Max. Torque |
n·m/r/min |
430/1500 |
|
Fuel type |
Diesel |
||
Standard of emission |
EN III |
||
Tire size |
8.25-16(optional7.50-16,7.50R16,8.25R16) |
||
Persons |
3 |
||
Optional Engine |
Engine model |
CA4DF3-14E3F |
|
Rated power |
kw |
103 |
|
Engine emission |
ml |
4752 |
|
Engine model |
BF4M2012-13E3 |
||
Rated power |
kw |
96 |
|
Engine emission |
ml |
4040 |
|
