Help CenterKaiFan Brand New 160 Ton Truck Crane QY16F
Related Products
-
KaiFan QY70U Truck CraneUS$ 1 - 100,000MOQ: 1 Unit -
KaiFan Brand New 50 Ton Truck Crane QY50GUS$ 10,000 - 200,000MOQ: 1 Unit
-
KaiFan QY25G Truck CraneUS$ 1 - 100,000MOQ: 1 Unit
-
Heavy Road Wrecker KFM5322TQZ08HUS$ 30,000 - 50,000MOQ: 1 Unit
-
Flatbed Road Wrecker KFM5084TQZ06PUS$ 30,000 - 50,000MOQ: 1 Unit
Specifications
QY16F truck crane1.Max. rated lifting capacity: 16000kg
2.Max. load moment of basic boom: 553 kn.m
“KAI FAN” Brand KFM5233JQZ16F(QY16F)Crane is fully hydraulic telescopic crane, the maximum rated lifting capacity is 16t. It can be applied in various conditions for lifting and installation work, such as industrial and mining establishments, building site, station, sea port, warehouse and so on.
Items |
Parameters |
|
Working Performance Parameters |
Max. Rated lifting weight |
16000 kg |
Max. Rated lifting force |
553 kn.m |
|
Max. Height of the basic boom |
10.4m |
|
Max. Height of the main boom |
24.3m |
|
Max. Height of boom and jib |
31.8m |
|
Working Speed |
Extension time of the lift boom |
25s |
Lifting time of the lift boom |
20s |
|
Turning speed |
0~2.5rpm |
|
Traveling Parameters |
Max. Traveling speed |
75 km/h |
Max. Grade ability |
26% |
|
Min. Turning radius |
11m |
|
Min. Ground clearance |
270mm |
|
Approaching angle |
16° |
|
Departure angle |
11° |
|
Elevation of the main boom |
-3°~80° |
|
Weight Parameters |
The whole weight |
23000 kg |
Load of the front axle |
6000 kg |
|
Load of the middle-rear axle |
17000 kg |
|
The whole weight of full load |
22805 kg |
|
Dimension Parameters |
External dimension(length×width×height) |
12000×2494×3330mm |
Vertical span of outrigger |
4.8m |
|
Horizontal span of outrigger |
5.4m |
|
Length of main boom |
9.8m~24.3m |
|
Length of vice boom |
7.5m |
|
Chassis |
Model |
TAZ5253J |
Engine model |
WP6-240 |
|
Rated power/speed |
176kw/2500rpm |
|
Max. Torque/rotate speed |
800n.m/1300~1600rpm |
|
