Lonking 6ton CDM860 Small Wheel Loader For Sale
US$ 1 - 10,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
Lonking
Model Number:
CDM860
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Lonking 6 Ton Wheel Loader CDM860 For SaleUS$ 1 - 10,000MOQ: 1 Unit -
Lonking Mini Hydraulic Wheel Loader CDM812D for SaleUS$ 1 - 10,000MOQ: 1 Unit
-
Lonking 5 Ton Brand New Wheel Loader CDM855US$ 1 - 10,000MOQ: 1 Unit
-
China Lonking 3 Ton Wheel Loader CDM833US$ 1 - 10,000MOQ: 1 Unit
-
Lonking Mini Wheel Loader 5 Ton CDM855FUS$ 1 - 10,000MOQ: 1 Unit
Condition
New
Brand Name
Lonking
Model Number
CDM860
Place of Origin
Fujian, China
Type
Front Loader
Moving Type
Wheel Loader
Rated Load
6ton
Certification
ISO9001
Warranty
Ony year warranty
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Lonking 6ton CDM860 Small Wheel Loader For Sale1. WEICHAI WD10G240E21 engine, 175 KW
2. Hydraulic system
Lonking 6ton CDM860 Small Wheel Loader For Sale
1. WEICHAI WD10G240E21 engine, 175 KW
2. Hydraulic system
3. Bucket capacity: 3.5M3
| Overall Data | Steering System | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Bucket Capacity (m3) | 3.5 | Type | Hydraulic Load Sensor System | |||||||||||||
| Rated Payload (kg) | 6000 | Cylinders-BorexStroke (mm) | 2-100X324 | |||||||||||||
| Operating Weight (kg) | 21500±200 | Steering Pump | Gear Pump | |||||||||||||
| Traction Force (kN) | 172±3 | System Pressure (MPa) | 16 | |||||||||||||
| Breakout Force (kN) Travel Speeds (km /h): | 200±3 | Flow Rate(L/min/rpm) Steering Angle | 176/2200 ±35° | |||||||||||||
| I | II | Ⅲ | IIII | Hydraulic System | ||||||||||||
| Forward | 6.4 | 11.1 | 17.4 29.2 | Lift Cylinders-BorexStroke (mm) | 2-180X864 | |||||||||||
| Reverse | 7.2 | 12.9 | 20.8 | 31.1 | Tilt Cylinder-BorexStroke(mm) | 1-220X626 | ||||||||||
| Engine | WEICHAI WD10G240E21 | Model of Working Pump | Gear Pump | |||||||||||||
| Rated Power (kW/rpm) | 175/2200 | Flow Rate (L/min/RPM) | 275/2200 | |||||||||||||
| Rated Torque (Nm/rpm) Starting Voltage (V) | 920/1400-1600 24 | System Pressure (MPa) Pilot Conteol System Pressure(MPa) | 16 2.5 | |||||||||||||
| Drive Train | Hydraulic Cycle Time, Rated Load in Bucket (In Second): | |||||||||||||||
| Torque Converter | Single-stage, Single-turbine, 3-element | Raise(Loaded) | Dump | Lower(Empty) | Total | |||||||||||
| Torque Ratio | 2.56 | 6.3 | 1.2 | 4.3 | 11.8 | |||||||||||
| Transmission | Fixed Shaft Hydraulic Shift Spur Gear | Electrical System | ||||||||||||||
| Gear | 4F/4R | System Voltage (V) | 24 | |||||||||||||
| Pressure of Transmission (MPa) | 1.7-1.9 | Battery(2 in series) (Ah) | 120 | |||||||||||||
| Main Reducer | Spiral Bevel Gear Single-stage Reduction | Lamp Voltage (V) | 24 | |||||||||||||
| Final Reducer | Planetary Reduction | Service Refill Capacity | ||||||||||||||
| Tire | 23.5-25 L-3 20PR | Fuel Tank (L) | 285 | |||||||||||||
| Brake System | Hydraulic Tank (L) | 285 | ||||||||||||||
| Service Brake | Air Drive, Four Wheel Brake (Dry) | Crankshaft(L) | 20 | |||||||||||||
| Setting Pressure (MPa) Parking Brake Emergency Brake | 0.78 Air Drive Brake Air Drive Brake | Transmission (L) Front Axle (L) / Rear Axle (L) | 45 28/28 | |||||||||||||
| Air Conditioning System (Optional) | ||||||||||||||||
| Heating Capacity (W) Cooling Capacity (W) | 5800 (±10%) 4500 (±10%) | |||||||||||||||
