Lonking Mini Hydraulic Wheel Loader CDM812D for Sale

Name: Lonking Mini Hydraulic Wheel Loader CDM812D for Sale
Brand: Lonking
SKU: 140719346
Availability: InStock

US$ 1 - 10,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Brand Name:

Lonking

Model Number:

CDM812D

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name Lonking

Model Number CDM812D

Place of Origin Fujian, China

Type Front Loader

Moving Type Wheel Loader

Rated Load 1.2ton

Certification ISO9001

Warranty Ony year warranty

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Lonking Mini Hydraulic Wheel Loader CDM812D for sale
1. Changchai 490B engine, 38 KW
2. Hydraulic system

Lonking Mini Hydraulic Wheel Loader CDM812D for sale

Overall Data								Steering System
Bucket Capacity (m³)							0.55	Type			Hydraulic Load Sensor System
Rated Payload (kg)							1200	Cylinders-BorexStroke (mm)				2-63X280
Operating Weight (kg)							4200	Steering Pump				Shared With Working Pump
Traction Force (kN)							31	System Pressure (MPa)				14
Breakout Force (kN) Max. Travel Speeds (km /h):							36	Steering Angle				±35°
	I				II			Hydraulic System
Forward	8.3				20.8			Lift Cylinders-BorexStroke (mm)				2-80X610
Reverse	7.7				19.0			Tilt Cylinder-BorexStroke(mm)				1-100X450
Engine					Changchai 490B			Working Pump				Gear Pump
Rated Power (kW/rpm)						38/2400		Flow Rate (L/min/RPM)				120/2400
Rated Torque (Nm/rpm) Starting Voltage (V)						173/1800 24		System Pressure (MPa)				16
Drive Train								Hydraulic Cycle Time, Rated Load in Bucket (In Second):
Torque Converter			Single-stage, Single-turbine, 3-element					Raise(Loaded)	Dump	Lower(Empty)			Total
Torque Ratio			3.7					4.5	1.2	2.2			7.9
Transmission			Fixed Shaft Hydraulic Shift Spur Gear					Electrical System
Gear			2F/2R					System Voltage (V)				24
Pressure of Transmission (MPa)							1.2-1.5	Battery(2 in series) (Ah)				180
Main Reducer		Spiral Bevel Gear Single-stage Reduction						Lamp Voltage (V)				24
Final Reducer		Planetary Reduction						Service Refill Capacity
Tire		11.00-16						Fuel Tank (L)				80
Brake System								Hydraulic Tank (L)				80
Service Brake		Air Drive, Four Wheel Brake (Dry)						Transmission (L)				16
Setting Pressure (MPa) Parking & Emergency Brake				0.78 Flexible Shaft Controlled Caliper				Front Axle (L) / Rear Axle (L)				8/8
Qingzhou Transmission Feicheng Axle Standard Bucket				Light-duty Grapple (ZZ)
