China Cheap 3ton Lonking Mini Wheel Loader CDM833

Name: China Cheap 3ton Lonking Mini Wheel Loader CDM833
Brand: LONKING
SKU: 140719314
Availability: InStock

US$ 1 - 10,000 MOQ: 1 Set

Key Specifications

Condition:

New

Brand Name:

LONKING

Model Number:

CDM833

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name LONKING

Model Number CDM833

Place of Origin Shanghai, China

Type Front Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 8185*3000*3465mm

Rated Load 3ton

Certification CE

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

chenggong wheel loader CG956C
Rated load:5ton
bucket capacity 3m3
wheelbase:3300mm
operation weight:18000KG

3 ton Lonking Wheel Loader CDM833 Hydraulic Steering System Powerful Weichai Engine Anti-abrasion Integral Cutting Edge

3 ton Lonking Wheel Loader CDM833

									Air Conditioning System
Overall Data									Steering System
Bucket Capacity (m³)								1.7	Type			Hydraulic Load Sensor System
Rated Payload(kg)								3000	Cylinders-Bore×Stroke(mm)				2-80×315
Operating Weight(kg)								10300±300	Steering Pump				Gear Pump
Traction Force(kN)								97±3	System Pressure(MPa)				14
Breakout Force(kN)								100±3	Flow Rate(L/min/rpm )				88/2200
Travel speeds (km/h):									Steering Angle				±35°
	I				II		III		Hydraulic System
Forward	6.5				12		32		Lift Cylinders-Bore×Stroke(mm)				2-125×784
Reverse	6.8				12.5		33.5		Tilt Cylinder-Bore×Stroke(mm)				1-140×553
Engine					WP6G125E22				Model of Working Pump				Gear Pump
Rated Power(kW/rpm)						92/2200			Flow Rate(L/min/rpm )				176/2200
Peak Torque(Nm/rpm)						500/1400-1600			System Pressure(MPa)				16
Starting Voltage(V)						24
Drive Train									Hydraulic Cycle Time, Rated Load In Bucket(In Second):
Torque Converter			Single-stage, Single-turbine, 3-elements						Raise(Loaded)	Dump	Lower(Empty			Total
Torque Ratio			3.5						5.5	1.3	3.7			10.5
Transmission			Countershaft power shift Transmission						Electrical System
Gear			3F/3R						System Voltage(V)				24
Pressure of Transmission(MPa)								1.2-1.5	Battery (2 in series)(Ah)				105
Main Reducer		Spiral bevel, 1-stage Reduction							Lamp Voltage(V)				24
Final Reducer		Planetary Reduction							Service Refill Capacity
Tire		17.5-25 L-3 12PR							Fuel Tank(L)				200
Brake System									Hydraulic Tank(L)				200
Service Brake		Single Circuit Caliper, Air Brake							Crankshaft(L)				17
Setting Pressure (MPa)				0.78					Transmission(L)				36
Parking & Emergency Brake				Flexible Shaft Controlled Caliper					Front Axle(L) /Rear Axle(L)				13/13
									Heating Capacity(W)				5800(±10%)
									Cooling Capacity(W)				4500(±10%)
