High Quality New 5ton Lonking Wheel Loader CDM855F for Sale

Name: High Quality New 5ton Lonking Wheel Loader CDM855F for Sale
Brand: LONKING
SKU: 140719322
Availability: InStock

US$ 1 - 10,000 MOQ: 1 Set

Key Specifications

Condition:

New

Brand Name:

LONKING

Model Number:

CDM855F

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name LONKING

Model Number CDM855F

Place of Origin Shanghai, China

Type Front Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 8185*3000*3465mm

Rated Load 5ton

Certification CE

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Lonking wheel loader CDM855F
Rated load:5ton
bucket capacity 3m3
wheelbase:3300mm
operation weight: 18000KG

5 ton Lonking Wheel Loader CDM855F Powerful Weichai Engine Hydraulic Load Sensing Control System Anti-abrasion Control Edge

5 ton Lonking Wheel Loader CDM855F

Overall Data								Steering System
Bucket Capacity (m³)							3	Type			Hydraulic Load Sensor System
Rated Payload(kg)							5000	Cylinders-bore×Stroke (mm)					2-100×324
Operating Weight (kg)							16600±300	Steering Pump					Gear Pump
Traction Force(kN)							150±3	System Pressure (MPa)					16
Breakout Force (kN)							170±3	Flow Rate (L/min/RPM)					176/2200
Travel speeds (km/h):								Steering Angle					±35°
	I				II			Hydraulic System
Forward	11.5				36.0			Lift Cylinders-bore×Stroke (mm)					2-180×721
Reverse	16.0							Tilt Cylinder-bore×Stroke (mm)					1-200×563
Engine					WEICHAI WD10G220E21			Model of Working Pump
Rated Power(kw/rpm)						162/2200		Flow Rate (L/min/RPM)					220/2200
Peak Torque(Nm/rpm)						850/1400-1600		System Pressure (MPa)					16
Starting Voltage(V)						24
Drive Train								Hydraulic cycle time, rated load in bucket(in second):
Torque Converte			Single-stage, Duo-turbine, 4-element					Raise(Loaded)	Dump	Lower(Empty)				Total
Torque Ratio			4.0					6.0	1.2	4.3				11.5
Transmission			Planetary Powershift Transmission					Electrical System
Gear			2F/1R					System Voltage(V)				24
Pressure of Transmission (MPa)							1.2-1.5	Battery (2 in series)(Ah)				120
Main Reducer		Spiral Bevel, 1-stage Reduction						Lamp Voltage (V)				24
Final Reducer		Planetary Reduction						Service Refill Capacity
Tire		23.5-25 L-3 16PR						Fuel Tank (L)				285
Brake System								Hydraulic Tank (L)				285
Service Brake		Single Circuit Caliper,Dry Brake						Crankshaft (L)				20
Setting Pressure (MPa)				0.78				Transmission(L)				45
Parking Brake Emergency Brake				Air Actuated Caliper Brake Air Actuated Caliper Brake				Front Axle(L) /Rear Axle(L)				23/23
