Price Mini 4ton Lonking Electric Wheel Loader CDM843

Name: Price Mini 4ton Lonking Electric Wheel Loader CDM843
Brand: Lonking
SKU: 140719324
Availability: InStock

US$ 1 - 10,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Brand Name:

Lonking

Model Number:

CDM843

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name Lonking

Model Number CDM843

Place of Origin Fujian, China

Type Front Loader

Moving Type Wheel Loader

Rated Load 4ton

Certification ISO9001

Warranty Ony year warranty

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Price Mini 4ton Lonking Electric Wheel Loader CDM843
Powerful Weichai Engine
Hydraulic Load Sensing Control System

Price Mini 4ton Lonking Electric Wheel Loader CDM843

									Air Conditioning System
Overall Data									Steering System
Bucket Capacity (m³)								1.7	Type			Hydraulic Load Sensor System
Rated Payload(kg)								3000	Cylinders-Bore×Stroke(mm)				2-80×315
Operating Weight(kg)								10300±300	Steering Pump				Gear Pump
Traction Force(kN)								97±3	System Pressure(MPa)				14
Breakout Force(kN)								100±3	Flow Rate(L/min/rpm )				88/2200
Travel speeds (km/h):									Steering Angle				±35°
	I				II		III		Hydraulic System
Forward	6.5				12		32		Lift Cylinders-Bore×Stroke(mm)				2-125×784
Reverse	6.8				12.5		33.5		Tilt Cylinder-Bore×Stroke(mm)				1-140×553
Engine					WP6G125E22				Model of Working Pump				Gear Pump
Rated Power(kW/rpm)						92/2200			Flow Rate(L/min/rpm )				176/2200
Peak Torque(Nm/rpm)						500/1400-1600			System Pressure(MPa)				16
Starting Voltage(V)						24
Drive Train									Hydraulic Cycle Time, Rated Load In Bucket(In Second):
Torque Converter			Single-stage, Single-turbine, 3-elements						Raise(Loaded)	Dump	Lower(Empty			Total
Torque Ratio			3.5						5.5	1.3	3.7			10.5
Transmission			Countershaft power shift Transmission						Electrical System
Gear			3F/3R						System Voltage(V)				24
Pressure of Transmission(MPa)								1.2-1.5	Battery (2 in series)(Ah)				105
Main Reducer		Spiral bevel, 1-stage Reduction							Lamp Voltage(V)				24
Final Reducer		Planetary Reduction							Service Refill Capacity
Tire		17.5-25 L-3 12PR							Fuel Tank(L)				200
Brake System									Hydraulic Tank(L)				200
Service Brake		Single Circuit Caliper, Air Brake							Crankshaft(L)				17
Setting Pressure (MPa)				0.78					Transmission(L)				36
Parking & Emergency Brake				Flexible Shaft Controlled Caliper					Front Axle(L) /Rear Axle(L)				13/13
									Heating Capacity(W)				5800(±10%)
									Cooling Capacity(W)				4500(±10%)
