Lonking 5ton 3m3 Wheel Loader CDM858

Name: Lonking 5ton 3m3 Wheel Loader CDM858
Brand: Lonking
SKU: 140719304
Availability: InStock

US$ 1 - 10,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Brand Name:

Lonking

Model Number:

CDM858

Oriemac Machinery & Equipment (Shanghai) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai port or Qingdao port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name Lonking

Model Number CDM858

Place of Origin Fujian, China

Type Front Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 2206mm*1160mm*1233mm

Rated Load 5ton

Certification ISO9001

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

5 ton Lonking Mini Wheel Loader CDM858
1. QSB6.7-C220 engine, 164 KW
2. Hydraulic system
3. Bucket capacity: 3M3

5 ton Lonking Mini Wheel Loader CDM858

Original Engine
ZF Transmission & Axles
Heavy Load Driving System
Pilot Control System
Automatic Leveling
ROPS/FOPS

									Air Conditioning System
Overall Data									Steering System
Bucket Capacity (m³)							3		Type			Hydraulic Load Sensor System
Rated Payload(kg)							5000		Cylinders-bore×Stroke(mm)				2-100×324
Operating Weight(kg)							18020±300		Steering Pump				Gear Pump
Traction Force(kN)							155±3		System Pressure(MPa)				16
Breakout Force(kN)							170±3		Flow Rate(L/min/rpm )				176/2200
Travel speeds (km/h):									Steering Angle				±35°
	I			II		III		IV	Hydraulic System
Forward	6.8			13		23		36	Lift Cylinders-bore×Stroke(mm)				2-180×721
Reverse	6.8			13		23			Tilt Cylinder-bore×Stroke(mm)				1-200×563
									Model of Working Pump				Gear Pump
Rated Power(kW/rpm)					164/2200				Flow Rate(L/min/rpm )				220/2200
Peak Torque(Nm/rpm)					949/1500				System Pressure(MPa)				16
Starting Voltage(V)					24				Pilot Control System Pressure(MPa)				2.5
Drive Train									Hydraulic cycle time, rated load in bucket(in second):
Torque Converter			Single-stage, Duo-turbine, 4-element						Raise(Loaded)	Dump	Lower(Empty)			Total
Torque Ratio			2.55						6	1	4			11
Transmission			Planetary Powershift Transmission						Electrical System
Gear			4F/3R						System Voltage(V)				24
Pressure of Transmission(MPa)							1.6-1.8		Battery (2 in series)(Ah)				120
Main Reducer		Spiral Bevel, 1-stage Reduction							Voltage(V)				24
Final Reducer		Planetary Reduction							Service Refill Capacity
Tire		23.5-25 L-3 16PR							Fuel Tank(L)				285
Brake System									Hydraulic Tank(L)				285
Service Brake		Full Hydraulic Wet-discs Brake							Crankshaft(L)				20
SettingPressure(MPa)		0.78							Transmission(L)				45
Parking Brake		Hydraulic Actuated Drum Brake							Front Axle(L) /Rear Axle(L)				28/28
Emergency Brake		Hydraulic Actuated Drum Brake							Front Axle(L) /Rear Axle(L)				28/28
									Heating Capacity(W)				5300(±10%)
									Cooling Capacity(W)				4500(±10%)
