2015 New Style Products Hot Sale the Best Price HOWO Dump Truck for Sale Made in China

Truck Model

ZZ3257N3647A (LHD)

Truck Brand

SINOTRUK –HOWO

Dimension(Lx W xH)(unloaded)

8214x2496x3386

Cargo body size (L*W*H, mm)

5400x2300x1400

Cargo body thickness(mm)

bottom:8mm, side:6mm,

Lift type of Carriage

Ventral lifting

Approaching angle/Departure angle(°)

19/26

Overhang(front/rear) (mm)

1500/1739

Wheel base (mm)

3625+1350

Max speed(km/h)

75

Curb weight(kg)

12290

Loading Weight(kg)

30000

Fuel tanker capacity

300L with locking fuel cap

Fuel consumption(L/100km)

32

Clutch

Single-plate dry clutch Φ420mm

Engine Model

(Steyr technology, made in China)

Model

WD615.47,4- stroke direct injection diesel engine, 6 cylinders in line with water cooling , turbo-charging and intercooling

Horse Power, max(kw/rpm)

336HP,247/2200

Emission Standard

EURO II

Transmission

Model

HW 19710,10 forwards and 2 reverse

Brake system

Service brake

Dual circuit compressed air brake

Parking brake

spring energy, compressed air operating on rear wheels

Auxiliary brake

Engine exhaust brake

Steering system

Model

ZF8098 hydraulic steering with power assistance

Front axle

HF9 , Steering with double T-cross section beam

Loading capacity:9000KG

Rear axle

HC16, Casting axle housing, central double reduction with differential locks between axles and wheels

Color

Optional

Tire

12.00-20 11 pieces
