Home > Products > Earthmoving Machinery > Heavy duty Changlin 5 Ton Wheel Loader 957H
Heavy duty Changlin 5 Ton Wheel Loader 957H
- 1000 Set / Sets per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Brand Name: | CHANGLIN | Model Number: | 957H |
Type: | Front Loader | Moving Type: | Wheel Loader | Dimension(Long * Breadth * High): | 8215*2800*3450mm |
Rated Load: | 5TON | Certification: | ISO CE | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
1 set for 40HQ container or RORO shipment or Bulk break shipment
Product Description
CHANGLIN wheel loader 957H
1. The 957H Wheel Loader is equipped with reliable ShangChai SC11CB220G2B1 engine.
2. This Wheel loader adopts 3 forward and 3 reverse power shift transmission.
3. The combined seal cylinder adopted by this wheel loader obtains high seal performance and more reliability.
Overall Dimension | |||
1 | Length(with bucket on ground) | 8130(mm) | |
2 | Width(to outside of wheels) | 2800(mm) | |
3 | Bucket width | 2946(mm) | |
4 | Height(To the top of the cab) | 3450(mm) | |
5 | Wheel base | 3200(mm) | |
6 | Tread | 2200(mm) | |
7 | Min. ground clearance | 450(mm) | |
Main Technical Specification | |||
1 | Rated load | 5000(Kg) | |
2 | Operating weight | 16700KG | |
3 | Rated bucket capacity | 3.0(m3) | |
4 | Max. breakout force | 160kN | |
5 | Max. traction force | 150kN | |
6 | Max. dump clearance | 3100(mm) | |
7 | Dump reach | 1150(mm) | |
8 | Dump angle at any position | ≥450 | |
9 | Digging depth(with bucket bottom horizontal) | 165(mm) | |
10 | Min. turning radius | ||
| (1) Outside of bucket | 6735(mm) | |
(2) Outside of front wheel | 6098(mm) | ||
11 | Pivot angle frame | 380 | |
12 | Oscillating angle of rear axle | +13o | |
13 | Lifting time of bucket | ≤5.6(sec.) | |
14 | Lowering time of bucket | ≤3.7(sec.) | |
15 | Dumping time | ≤1.7(sec.) | |
16 | Traveling speed(Km/h),3 forward and 3 reverse | ||
| (1) 1st gear | 7.05/9.0 | |
(2) 2nd gear | 11.7/16.0 | ||
(3) 3rd gear | 34.6/38.24 | ||
Diesel engine | |||
1 | Model | ShangChai SC11CB220G2B1 | |
2 | Type | Direct injection. Turbocharge. Water cooling | |
3 | Rated output | 162(Kw) | |
4 | Inter-bore of cylinder/stroke | 121/152(mm) | |
5 | Total exhaust of cylinder | 10.5(L) | |
6 | Model of starting motor | KB-24V | |
7 | Power of start motor | 7.5(KW) | |
8 | Voltage of starting motor | 24(V) | |
9 | Rated speed | 2200(r/min.) | |
10 | Max. Torque | 843±6%(N.m)/(1400r/min) | |
11 | Starting type | Electric | |
12 | Min. specific fuel consumption | 230(g/Kw.h) | |
13 | Engine specific oil consumption | 0.95-1.77(g/Kw.h) | |
14 | Net weight | 960(Kg) |
