Home > Products > Earthmoving Machinery > Low Price Hydraulic Joystick Control 3 Ton Used Wheel Loader With Pallent Fork
Low Price Hydraulic Joystick Control 3 Ton Used Wheel Loader With Pallent Fork
- 1000 Unit / Units per Month
- shanghai
- T/T Credit Card
Product Details
Condition: | New | Brand Name: | changlin | Model Number: | 936 |
Place of Origin: | Hunan, China | Type: | Other, wheel loader | Moving Type: | Wheel Loader |
Dimension(Long * Breadth * High): | 6923*2305*3136 mm | Rated Load: | 3 tons | Certification: | ISO & CE |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
nude package
Product Description
Low Price Hydraulic Joystick Control 3 Ton Used Wheel Loader With Pallent Fork
1)Adopting the strong power, low fuel consumption.
2)Bivariate system uses a unique sub-structure, easy maintenance and smooth power transmission.
3)Unit time for loading and unloading of materials Σt = t1 + t2 + t3 = 9.2s.
4)The state-of-the-art hydraulic system design, not only to improve the work system's ability to shovel, but also the oil temperature of the hydraulic system ,so that prolong the service life of the hydraulic components.
5)Can be equipped with automatic hammer,snow-shoving board, coal buckte,rock bucket,high-dump device are available.
Main Specification | Unit | |
Bucket Capacity | m3 | 1.7 |
Rated Load | kg | 3000 |
Max. Digging Force | kn | 96 |
Max. Traveling Force | kn | 105 |
Operating Weight | kg | 10200 |
Model of Engine | TD226B/YuchaiYC6B125 | |
Rated Power | kw | 92 |
Rated Speed | r/min | 2200 |
Max. Torque | N.m | 500 |
Forward Travelling Speed | km/h | 6.6/13.8/30.1 |
Reverse Travelling Speed | km/h | 8.2/17/29 |
Max. Grade Ability | 27° | |
Steering Angle | ±38° | |
Mini Steering Radius | mm | 4885 |
Lifting Time | s | 5.1 |
Lowering Time | s | 3.0 |
Dumping Time | s | 1.1 |
Standard Tyre | 17.5-25-12PR | |
Dumping Clearance (45°) | mm | 2934 |
Dumping Reach (45°) | mm | 1043 |
Dimension(L*W*H) | mm | 6923*2305*3136 |
Company Profile
Shanghai Evangel Industrial Co., Ltd. is a leading Chinese construction machinery exporter, affiliated with Evangel International Machinery Limited, located in the downtown of Shanghai City. Since our company was founded, based on the advantage of XCMG which is the No.1 Chinese construction machinery manufacturer, we continually introduce Chinese excellent construction machinery enterprises and their products to international markets, such as SANY, ZOOMLION, CHANGLIN, LIUGONG, SDLG, HOWO, SHANTUI, HBXG, YTO, BEIBEN etc. We not only make more international customers know and approbate our products, but also gradually build up friendship with construction machinery customers all over the world.
Our Strengths are as follows:
(i) Eight years professional experience in international trading and rich knowledge in construction machinery & heavy equipment industry, which enable us to turn customer inquiries into final products and export them to numerous countries and regions without barriers;
(ii) A well educated and friendly sales team with international vision, members of which can speak fluent multiple languages, such as English, Spanish, Portuguese, Russian, Arabic and French etc;
(iii) Strong long term dealership from various top manufacturers, assuring that all our products are original brand new ones with competitive price;
(iv) Excellent logistics services (by sea, air, railway or road), ensuring timely delivery of consignments all over the world;
(v) Comprehensive after-sales service, including one year warranty, spare parts supply, installment and maintenance, and training;
(vi) An expertly managed ERP system and a well coordinated quality control system to satisfy various client requirements.
EVANGEL has passed the international quality management system of ISO9000, CE, SGS, UL and other products certification. We have an excellent after-sales service system in the interests of customers to establish good strategic partnerships with agencies around the world. We won the good reputation from reliable quality, competitive price and excellent after-sales service. Our export revenue increases constantly every year, and our products have already entered nearly 100 countries across the continents of South America, Africa, Middle East, Australia, Russia, Middle Asia, South Asia, Southeast Asia, and East Europe. We sincerely hope to cooperate, develop together and build a good future with you.
EVANGEL, your best choice for construction machinery in China!
