Home > Products > Earthmoving Machinery > hot sale machinery Changlin 957 wheel loader
hot sale machinery Changlin 957 wheel loader
- 100 Set / Sets per Month
- Shanghai port
- T/T Credit Card
Product Details
Condition: | New | Brand Name: | Changlin wheel loader | Model Number: | 957H/S/Z wheel loader |
Place of Origin: | Jiangsu, China | Type: | Front Loader | Moving Type: | Wheel Loader |
Dimension(Long * Breadth * High): | 8130*2946*3450mm | Rated Load: | 5t | Certification: | ISO |
Warranty: | 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
one unit in one 40HQ container or RORO/Bulk Break
Product Description
1. Engine type: Shangchai C6121 engine
2. Rated power: 162Kw
3. Bucket capacity: 3m3 .
4. Operating weight: 16700kgs
Parameter: wheel loader
Overall Dimension | |||
1 | Length(with bucket on ground) | 8130(mm) | |
2 | Width(to outside of wheels) | 2800(mm) | |
3 | Bucket width | 2946(mm) | |
4 | Height(To the top of the cab) | 3450(mm) | |
5 | Wheel base | 3200(mm) | |
6 | Tread | 2200(mm) | |
7 | Min. ground clearance | 450(mm) | |
Main Technical Specification | |||
1 | Rated load | 5000(Kg) | |
2 | Operating weight | 16700KG | |
3 | Rated bucket capacity | 3.0(m3) | |
4 | Max. breakout force | 160kN | |
5 | Max. traction force | 150kN | |
6 | Max. dump clearance | 3100(mm) | |
7 | Dump reach | 1150(mm) | |
8 | Dump angle at any position | ≥450 | |
9 | Digging depth(with bucket bottom horizontal) | 165(mm) | |
10 | Min. turning radius | ||
| (1) Outside of bucket | 6735(mm) | |
(2) Outside of front wheel | 6098(mm) | ||
11 | Pivot angle frame | 380 | |
12 | Oscillating angle of rear axle | +13o | |
13 | Lifting time of bucket | ≤5.6(sec.) | |
14 | Lowering time of bucket | ≤3.7(sec.) | |
15 | Dumping time | ≤1.7(sec.) | |
16 | Traveling speed(Km/h),3 forward and 3 reverse | ||
| (1) 1st gear | 7.05/9.0 | |
(2) 2nd gear | 11.7/16.0 | ||
(3) 3rd gear | 34.6/38.24 | ||
Diesel engine | |||
1 | Model | ShangChai SC11CB220G2B1 | |
2 | Type | Direct injection. Turbocharge. Water cooling | |
3 | Rated output | 162(Kw) | |
4 | Inter-bore of cylinder/stroke | 121/152(mm) | |
5 | Total exhaust of cylinder | 10.5(L) | |
6 | Model of starting motor | KB-24V | |
7 | Power of start motor | 7.5(KW) | |
8 | Voltage of starting motor | 24(V) | |
9 | Rated speed | 2200(r/min.) | |
10 | Max. Torque | 843±6%(N.m)/(1400r/min) | |
11 | Starting type | Electric | |
12 | Min. specific fuel consumption | 230(g/Kw.h) | |
13 | Engine specific oil consumption | 0.95-1.77(g/Kw.h) | |
14 | Net weight | 960(Kg) |
