Help CenterCarbonated Beverage Filling Machine(CO2 Drink Filling Machine)
Related Products
-
Carbonated Soft Drink Production LineUS$ 30,000 - 150,000MOQ: 1 Set -
3 in 1 Carbonated Soft Drink Filling MachineUS$ 15,000 - 100,000MOQ: 1 Set
-
Carbonated Drink Production LineUS$ 15,000 - 100,000MOQ: 1 Set
-
3 in 1 Carbonated Drink FillerUS$ 15,000 - 100,000MOQ: 1 Set
-
3 in 1 Carbonated Drink Filling LineUS$ 15,000 - 100,000MOQ: 1 Set
Specifications
soft drink filling machineCO2 drink filling machine
Material:stainless steel
Max capacity: 36000BPH
Main Composing:
1. RO/UF Water treatment equipment
2. Preform injection molding machine
3. Cap injection molding machine
4. PET bottle blowing molding machine
5. Fully automatic bottle unscrambler,
6. Air conveyer
7. Rinsing filling capping machine
8. Lamp inspection
9. OPP/PVC labeling machine
10. Code printer
11. Wrap shrinking packing machine
12. Carton packing machine
13.Palletizer
Specification:
Model | QGF14-12-5 | QGF18-18-6 | QGF24-24-8 | QGF32-32-10 | QGF40-40-12 |
Production capacity(500ml) (bph) | 4000 | 8000 | 12000 | 15000 | 18000 |
Filling precision | >±5mm(Liquid Level) | ||||
Polyester bottle standard(mm) | Bottle diameter: 50-100mm Bottle Height: 150-320mm | ||||
Suitable cap sharp | Plastic screw cap | ||||
Water pressure of washing bottle(Mpa) | 0.18 | ||||
Water consumption of washing bottle(kg/h) | 800 | 1600 | 2500 | 3500 | 4500 |
Spraying position | 5 | 5 | 6 | 12 | 20 |
Dripping position | 3 | 3.5 | 14 | ||
Air source pressure(Mpa) | 4 | ||||
Air consumption(m3/min) | - | 0.3 | 0.4 | 0.5 | 0.6 |
Power (kw) | 4.23 | 5..03 | 6.57 | 8.07 | 5.6 |
Weight (kg) | 2500 | 3000 | 4000 | 5000 | 6000 |
Size(mm) | 2300×1550×2500 | 2640×1800×2500 | 3000×2000×3150 | 3600×2800×3150 | 4500×3400×3150 |
Machine Picture
