Product Details
Place of Origin: | Hebei, China | Brand Name: | HTK | Model Number: | HTK-2400 |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
15000T 13.5mm to 4-11mm cold-rolled ribbed steel bars machines
(1)Introduction of Rebar/Bar Ribbed Steel Cold Rolling Machine
1 Derusting Machine
The machine is close type, there have three rotary wheels inside, we could adjust it up and down, it is easier for the raw materials installation, we could put the wire rod inside, then adjust the wheels.
2. Rolling mill
The rollers’ angle should be 120°, at the same center, first rolling mill is mainly for reducing the diameter, second set of rolling mill is for making the rebar,
3. Plate Machine
The machine is with electromagnetic motor, it offer the power for the whole line, the motor speed could be adjusting, it will change the rolling speed.
4. Stress-Relieving Machine
This machine is mainly for reducing the machine hardness.
5. The Wire Drawing Machine matches the moment type motor, the mainly spare parts is the wire wheel
6.Straight Machine and Cutter
(2)Parameters of Rebar/Bar Ribbed Steel Cold Rolling Machine
Item |
Small type YHT210 |
Medium type YHT228 |
Large type YHT285 |
Unit |
Raw matrial | φ6.5-10 | φ6.5-12 | Φ10-16 | mm |
Roller Diameter | Φ210 | Φ228 | Φ285 | mm |
Power | 55-75 | 75-110 | 130-160 | KW |
Center distance between gears | 650 | 650 | 700 | mm |
Rolling speed | 1.5-2 | 1.5-3 | 2-3 | m/s |
Cutting length | 1.5-12 | 1.5-12 | 1.5-12 | m |
Motor of flying shear | 5.5 | 7.5 | 15 | KW |
Product specification | Φ5-8 | Φ5-10 | Φ8-14 | mm |
Output | 20-35 | 25-50 | 60-80 | T/Shift |
One 20ft container/Set
Package: Stretch Film or Pallet
Main Farm Fence Wire Machinery: 1 Unit
Coil Holder: Several Units
Tool Cabinet: 1 Unit
Spare Parts: Several Units
Payment:30% TT for advance payment, 70% TT after the copy of B/L.
1.Farm Fence Wire Machinery Warranty: One Year.
2.Enough spare parts of machines could be supplied.
3.All machines were tested and adjusted before delivery.
4.Engineers available to service machinery overseas: Worker-training, installation.etc.
5.24 hours technical support by e-mail or calling service.
Our Factory:HEBEI HTK WELDING EQUIPMENT CO.,LTD.
We have 3 senior engineers,105senior technicians, more than 100 employees
- Our products: Field Fence and Farm Fence Wire Machine, Welded Wire Mesh Machine
- Our certifications: ISO 9001:2000, BV certification
- Our Main Market:South Africa, Mongolia, Asia, Dubai
Advantage of HTK Factory:
- We have professional engineer supervision
- The price preferential benefit
- Product quality assurance
- High production efficiency
- With credibility and protection
- Can visit the factory in person
- Good after sales service
- Business model: Factory direct
MOQ: 1 Set Farm Fence Wire Machinery.
