used iron wire drawing machine for drawing steel iron wire supplied by china manufacturer
- 30 Set / Sets per Month
- Tianjin-xiangang
- T/T Credit Card
-
4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
-
Jotun JT-SDJ Industrial Automatic Metal Sheet Surface Polishing Machine
-
Large Metal Sheet Metal Workpiece Processing Deburring Chamfering Plane Belt Polishing Machine
-
Heavy Duty Automatic Wide Belt Metal Sand Deburring Machine
-
Metal Plate Deburring and Rust Removal Machine Steel Plate Sand Belt Drawing and Polishing Equipment Flat Polishing Machine
-
Metal Flat Sheet Laser Cutting Parts Deburring Grinding Polishing Machine Manufacturer
Product Details
| Place of Origin: | Hebei, China | Brand Name: | CY | Model Number: | WDM-0211 |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
used iron wire drawing machine for drawing steel iron wire supplied by china manufacturer
Main Specification
Type | LW-1/800 | LW-1-6/560 | LW-1-7/450 | LW-1-6/350 |
Material intensity |
| δb≥110kg/mm2 | 128kg/mm2 | δb≥140kg/mm2 |
Max diam of material | 10-14 | 6.5mm | 3.4mm | 2.5mm |
Min diam of material | 6.0 | 2mm | 1mm | 0.75mm |
Diam of block | 1-800 | 1-6/560 | 1-7/450 | 1-6/350 |
Max average condensation | 25% | 30% | 20% | 21% |
Total condensation |
| 78-88.5% | 77.9% | 78% |
Max.speed of block | 60m/min | 245m/min | 346.9m/min | 200m/min |
Total power | 80kw | 18.5-30kw | 7.5-11kw | 7.5-11kw |
Weight | 4500kg | 2000kg | 1500kg | 1000kg |
Overal size | 9730×3340×2020mm | 1700×1150×1750mm | 1520×810×1700mm | 1400×800×1500mm |
Main Featrues
1.Precise design, easy operation.
2.High speed and stability fitting your goal of efficiency.
3.Made from high quality material, undergoing high abrasion-resistance and low deformation heat treatment process, the machine is endurable with long time preciseness.
4.The forced feed lubricator guarantees oil-film lubrication of the rubbing parts and ensures the lasting use of the machine.
wire drawing machines can be ordered according customer's request
Machine to be installed and commissioned by SM technicians.
The seller will send our engineer to install the machine accordingly if the buyer need.
The buyer have to pay the salary US$100 per day, and the air ticket, accommodation, eating and some related fees should be your responsibility.
It is in same condition if the buyer need the seller to send the interpreter.
we also produce others machine,the following is our others machines:
welded wire mesh machine
barbed wire machine
chain link fence making machine
nail making machine
wire drawing machine
grassland fence making machine
expanded metal mesh machine
shuttless weaving mesh machine
pvc wire coating machine
roof and wall steel panel roll forming machine
if you have any question,please contact with me as soon as possible.and welcome to visit our factory
contactor:Lily Zhai
skype:htkmachine
whatsapp:0086 13463185792
wechat: lilyzhai66
QQ :763185887
