Help CenterTransparent Speaker Wire
Related Products
Specifications
Transparent Speaker Wire1.Good quality
2..Favorable price
3..Attractive design
4.OEM and ODM service provided
Transparent Speaker Wire
1)conductor:BC TC CCA
2)Insulation:PE PVC
3)we have do this for about ten years
4)high quality and competitive price.
Usage:
This sound cable is used for connecting power amplifier and broadcasting system, for transmitting the audio signals amplified by the amplifier.
Payment
1.T/T
We need to get 30% advance payment first. The left should be paid before shipment. The customer should pay the left when he receives the copy B/L, then we will send the customer the whole original documents by post.
2.L/C
The terms of payment we usually adopt are confirmed and irrevocable L/C
Payment by L/C at sight is the only mode we accept.
basic Construction
Transparent Type | ||||
2 cores |
Number of core & normal area (mm^2) |
Structure (mm) |
Thickness of insulation (mm) |
Approx diameter (mm) |
2*0.50 |
7*9/0.10 |
0.7 |
2.20*4.40 |
|
2*0.75 |
7*14/0.10 |
0.7 |
2.40*4.80 |
|
2*1.00 |
7*18/0.10 |
0.8 |
2.60*5.20 |
|
2*1.50 |
7*27/0.10 |
0.9 |
3.10*6.20 |
|
2*2.00 |
7*36/0.10 |
1 |
3.90*7.80 |
|
2*2.50 |
7*45/0.10 |
1.2 |
4.20*8.40 |
|
2*4.00 |
7*72/0.10 |
1.3 |
4.80*9.60 |
|
|
|
|
|
|
PVC Type |
|
|||
Number of core & normal area (mm^2) |
Structure (mm) |
Thickness of insulation (mm) |
Approx diameter (mm) |
|
2*0.50 |
28/0.15 |
0.8 |
2.40*4.80 |
|
2*0.75 |
42/0.15 |
0.8 |
2.50*5.10 |
|
2*1.00 |
32/0.20 |
0.8 |
2.80*5.70 |
|
2*1.50 |
48/0.20 |
0.9 |
3.20*6.50 |
|
2*2.50 |
49/0.25 |
0.9 |
3.60*7.40 |
|
2*2.40 |
56/0.30 |
1 |
4.30*8.80 |
|
2*6.00 |
84/0.30 |
1 |
4.80*9.80 |
|
packing:
1) Packing lengths: 100m/roll, 200m/roll, 300m/roll, 100 yards/roll,
200 yards/roll, 300yard/roll
2) Inner packing: wooden drum, plastic drum, paper drum
3) Outer packing: carton box, pull out box
4) Other packing available according to client's request
Why choose us
1.High quality
2.Favorable price
3.Great variety of products
4.Attractive design
5.Environment friendly technology
