USB 0~30VdC Voltage Data Logger 32K Memory w/ Temp. RH Without LCD Display Made in Taiwan
Features:
- USB datalogger shape with NEW DESIGN patent
- Logger stores up to 32,000points voltage from 0 to 30Vdc
- Unique to integrate ambient Temp. and relative humidity monitoring and total records up to 32,000 points
- Smart logger with tripod receptacle and wrist strip for long time recording and fix on the wall
- Easy to connect to a current loop transmitter or device
- Software compatible with windows 98 / 2000 / XP / Vista / 7
- USB Interface for Set-up and Data Download.
- Bright red ,green LEDs
- Start and stop modes are selectable by pressing button or program (set up) from friendly software
- Special design with flat button (key) design for preventing accidently touch to stop or activate logging function
- Data can be saved, printed and exported to many other applications connecting to a current source sensor, connecting to a current sink sensor.
- It complies with all essential health and safety requirements set out in European Directives (CE marking)
- Made in Taiwan
Specifications:
- Record data : Voltage 0~30VdC
- No LCD display
- Input : Single
- Temperature RH
- Range : -20~60°C (-40~140°F)
- Resolution : 0.1°C / °F , 0.1 % RH
- Accuracy : ±0.6 °C (-0~50°C),others ±1.2°C
- Resolution : 1mV
- Accuracy :
- Voltage: ±2mV(0~10V) ,±5mV(0~30V)
- Temp.±1°C/2°F
- RH : ±5%(At 25°F)
- LED (Red,Green)
- Sample Interval : 0~59 seconds. 0~59 minutes, 0~6 hours selectable
- Hi / Lo threshold setting
- Logger mode : Immediately, Key start/stop , Schedule , Rollover when memory is full , Real-time
- Relative Humidity (RH%)
- Range : 10~90% RH
- Resolution : 0.1%RH
- Accuracy : ±5% RH
- Memory Capacity : 32000
- Power : 3.6 Lithium battery 1/2AA x 1 pc
- Operating Temp. : 0~50°C(32~122°F)
- Operating RH : <80%
- Logger size : 135.7 x 28.5 mm
Set Includes:
- 1 x USB voltage data logger
- Test leads wire with crocodile clips black and red
- 1 x Instruction Manual
- 1 x 3.6 Battery
- 1 x Wrist strip
- 1 x CD software
- 1 x USB cap
