USB Current Loop 4-20mA Data Logger With Temp.RH no LCD 32K Memory Made in Taiwan

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Taiwan, China

Model Number:

M01985445

Usage:

Other, Indoor / Outdoor

Gain Express Holdings Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Taiwan, China

Model Number M01985445

Usage Other, Indoor / Outdoor

Theory Other, Current loop data logger

Accuracy ±0.004mA

Features:

USB datalogger shape with NEW DESIGN patent
Store up to 32,000points current loop from 4 to 20mA
Records not only the current but also Temp. and Relative Humidity (RH)
Smart logger with tripod receptacle and wrist strip for long time recording and fix on the wall
Easy to connect to a current transmitter or automotive device, such as vehicle current, or other current source
Software compatible with windows 98 / 2000 / XP / Vista / 7
USB Interface for Set-up and Data Download.
Bright red ,green LEDs
Start and stop modes are selectable by pressing button or program (set up) from friendly software
Special design with flat button (key) design for preventing accidently touch to stop or activate logging function
Data can be saved, printed and exported to many other Applications
It complies with all essential health and safety requirements set out in European Directives (CE marking)
Made in Taiwan

Specifications:

Record data: 4-20mA with Temp.RH
NO LCD display
Temperature RH
- Range: -20~60°C (-4~140°F)
- Resolution: 0.1°C / °F , 0.1% RH
- Accuracy: ±0.6°C (-0~50°C), others ±1.2°C
Resolution : 0.002mA
Accuracy : ±0.004mA
LED (Red, Green)
Sample interval : 0~59 seconds 0~59 minutes, 0~6 hours selectable
Hi / Lo threshold setting
5 Logger mode :
- Immediately
- Key start/stop
- Schedule
- Rollover when memory is full
- Real-time
Relative Humidity (RH%)
- Range : 10~90% RH
- Resolution : 0.1% RH
- Accuracy : ± 5% RH
Memory Capacity : 32000
Power : 3.6 Lithium battery
Operating Temperature : -20~60°C (-40~140°F)
Operating RH : <80%
Logger size : 135.7 x 28.5mm
