Plastic and Paper Hot Sealing and Packing Machine for Toys,stations,battery,foods,commodity,small Tools

The use of products
Applicable to the pharmaceutical, food, health products, medical equipment and other industries the capsule, tablet, pill, candy, disposable syringes and special-shaped material of plastic, paper and plastic, aluminum composite sealing packaging.
Detailed product description:
This product belongs to my company's innovative design of drug packaging machinery, its function to reach the domestic advanced level. Applicable in the pharmaceutical, capsule health care products, food, cosmetics, medical equipment, and so on, tablets, bolus, candy, liquid, paste, disposable syringes and special-shaped material of aluminum, paper and plastic, aluminum composite sealing packaging. The machine by microcomputer program control, frequency control, touch panel operation, high degree of automation, is an ideal blister packaging equipment. Products have passed the provincial technical appraisal.
Product features
1, molding, heat sealing, batch number, indentation, blanking device all adopt mandrel positioning rack, rocking the rocking handle, various devices can on the mandrel easily mobile, the machine is provided with the scale, convenient correcting, position quickly and accurately.
2, traction manipulator, the double swing rod apparatus, increases the traction stroke adjustable range (up to 180mm), can adapt to various sizes of medicine plate packaging. Machine version of the heating, the positive pressure forming, reticulate, cylinder heat sealing, automatic feeding, automatic indentation batch number, blanking section, the operation is simple and operation is reliable.
3, positive pressure air forming and equipped with mechanical punch, ensure the blister forming crisp uniform, applicable in large dense pill, medical devices and other large size or special shapes packaging; with special automatic feeder, adapt to the ampoule, ampoules, vials of packaging, applicable range wide.
4, the main drive part adopts parallel shaft helical gear reduction box, forming, heat sealing, indentation and other molds using xiao ding positioning, pressing plate fixed, accurate positioning, easy to change the mold, save the package material.
5, in order to facilitate the machine into the workshop, the body can be made according to user requirements.
Note: 1, optional with the cursor tracking on the version of the sealing device.
2, optional organic glass cover.
3, optional inkjet coding (word) device.

Technical parameter:
Punching frequency (6-50/min)
Production capacity (million/time) 3.5-23
Maximum molding area and depth (mm) 240*170*26 (standard 240*14*150)
Range of travel (mm) 40-160 (according to user requirements to increase to 180 mm)
Standard section (mm) 80*57 (according to user requirements design)
Air pressure (MPA) 0.4-0.6
The air flow rate is greater than or equal to 0.3m3/min
Power total power 50Hz 6.2kw 380V/220V
Main motor power (kw) 1.5
PVC hard piece (mm) 0.15-0.5*250
PTP aluminum foil (mm) 0.02-0.035*250
Dialysis paper (mm) 50-100g*250
Mold cooling water or circulating water
External dimensions (mm) 3000*730*1600 (L*W *H)
Whole weight (kg) 1400

Product picture:

Certification:
