Specifications
150kw Power Generator1.original volvo penta diesel engine
2.stamford,leroy somer ac alternator
3.electric injection
4.ce
AC 380V Volvo Penta Engine 150kw Power Generator With Converter
volvo have been widely used in large and small automobiles, heavy-duty trucks, engineering machineries and ships. Moreover, they are the ideal drive force of power generation sets. Volvo engines have high load capability as well as fast and reliable cold start performance
150KW/187.5KVA diesel generator | |
Set Type: | GNRV150 |
Standby Power: | 150KW/187.5KVA |
Prime Power: | 136KW/170KVA |
Rated Current: | 245(A) |
Rated Frequency: | 50(Hz) |
Start-up time: | 5~6(s) |
Power Factor: | 0.8(Lag) |
Rated Voltage: | 400/230(V) |
Diesel Engine Data | |
Manufacturer: | VOLVO |
Model: | TAD732GE |
Standby/Prime Power: | 178KW/162KW |
Rated Speed: | 1500(r/min) |
Cycle: | 4 stroke |
Cylinder Arrangement: | 6 in line |
Displacement: | 7.15L |
Bore and Stroke: | 108*130(mm) |
Compression Ratio: | 18:1 |
Governor Type: | Electronic |
Start battery voltage: | 24V DC |
|
|
Air Intake System | |
Air Intake System: | Turbo, Air/Air Cooling
|
Max Intake Restriction: | 3.5kpa |
Burning Capacity: | 12.4m3/min |
Air Flow: | 222 m3/min |
|
|
Exhaust System | |
Exhaust Gas Flow: | 35.1m3/min |
Exhaust Temperature: | 542°C |
Max Back Pressure: | 5kPa |
|
|
Fuel System | |
Fuel System: | Directly Injection Fuel System, Bosch Pump |
100%( Prime Power) Load: | 196g/kwh |
50%( Prime Power) Load: | 211g/kwh |
|
|
Oil System | |
Total Oil Capacity: | 29L |
Oil Consumption: | ≤0.08L/h |
Engine Oil Tank Capacity: | 31L |
Oil Pressure at Rated RPM: | 480kPa |
|
|
Cooling System | |
Cooling Way: | Water-cooled |
Total Coolant Capacity: | 37.1L |
Thermostat: | 87-102°C |
Max Water Temperature: | 105°C |
|
|
Alternator Data | |
| |
| Alternator Brand | Stamford,LeroySomer, Marathon,Engga |
Excitation Mode: | Brushless and self- exciting |
Number of phase and Access Act: | 3-phase 4-wire |
Connecting Type: | “Y” type connecting |
Alternator Capacity: | 187.5KVA |
Alternator Efficiencies: | 95% |
Overload: | (PRP)110% load can run 1h |
Protection Level: | IP21-23 |
Insulation Class, Temperature Rise: | H/H |
Control system:
1) Automatic alarm system: the unit hasunit has the acousto-optics alarm system and arreand arrestor for anr for any situation as the start defeat, the water is over tempeer temperature, the oil pulls down, over speed, over load and over current
2) Operation display:
i) Unit voltage, tri-phase load current and frequency display
ii) Water temperature, oil pressure display
iii) Fuel level, fuel temperature display
iv) Audible Audible and visual alarm lamps and buzzers
optional:
1)Auto-remove Monitor Panel
2)Auto Transfer System(ATS)
3)Auto-combine Cabinet
4)Sound proof canopy
5)Intelligent controlling system
