Specifications
1)Yanmar engine from Japan2)Stamford,Marathon alternator
3)Deepsea,ComAp control module
4)1 year warranty
Genor diesel generator set install original Yanmar diesel engine from Japan, with Stamford or Marathon alternator and Auto-start controller.
| Genset Model | Prime Power | Standby Power | Engine Model | NO. of Cylinders | Dimension (mm) | Net Weight | ||
| KW | KVA | KW | KVA | L x W x H | (kg) | |||
| GNR7YM | 7 | 8.8 | 7.7 | 9.6 | 3TNV76 | 3 | 1580*810*930 | 300 |
| GNR8.5YM | 8.5 | 11 | 9.4 | 12 | 3TNV82A | 3 | 1580*810*930 | 320 |
| GNR10YM | 10 | 13 | 11 | 14 | 3TNV88 | 3 | 1580*810*930 | 359 |
| GNR12YM | 12 | 15 | 13 | 17 | 3TNV84T | 3 | 1580*810*930 | 422 |
| GNR16YM | 16 | 20 | 18 | 22 | 4TNV84T | 4 | 1580*810*990 | 467 |
| GNR25YM | 25 | 31 | 28 | 34 | 4TNV98 | 4 | 1580*810*990 | 467 |
| GNR32YM | 32 | 40 | 35 | 44 | 4TNV98T | 4 | 1580*810*1165 | 667 |
| GNR40YM | 40 | 50 | 44 | 55 | 4TNV106 | 4 | 1580*810*1165 | 730 |
| GNR45YM | 45 | 56 | 50 | 62 | 4TNV106T | 4 | 1580*810*1165 | 730 |
Diesel engine: Yanmar engine
a) Governer Method:electrical or mechanical governor
c) Wind-cooled or Water cooled
d) Intake method:Natural apirated or turbocharged
Alternator
a) alternator: Leroy Somer, Stamford, or Marathon etc.
b) Inspiration Method: Natural Aspirated or Turbocharged
c) Excitation Way: Brushless Excitation
d) Governor Method: Electrical or Mechanical Governor
e) Cylinder:3L~ 4L
f ) 3ph:star,delta
g) Rated power factor:0.8(lagged)
h) Standard 2/3 pitch windings
i) Voltage Regulation:± 0.5%
j) Exciter type:PRET or Shunt
k) Votagle regulator: AVR (Automatic Voltage regulator)
Control system:
a)Automatic alarm system: the unit has the acoustic-optics alarm system and arrestor for any situation as the start defeat, the water is over temperature the oil pulls down, over speed, over load and over current
b) Operation display:
i)Unit voltage, tri-phase load current and frequency display
ii)Water temperature, oil pressure display
iii)Fuel level, fuel temperature dieplay
iv)Audible and visual alarm lamps and buzzers
c)Emergency stop button
d)Three protection
