Specifications
1)Yanmar engine from Japan2)Stamford,Marathon alternator
3)Deepsea,ComAp control module
4)68dB at 7m away
Genor diesel generator set install original Yanmar diesel engine from Japan, with Stamford or Marathon alternator and Auto-start controller.
| Genset Model | Prime Power | Standby Power | Engine Model | NO. of Cylinders | Dimension (mm) | Net Weight | ||
| KW | KVA | KW | KVA | L x W x H | (kg) | |||
| GNR7YM | 7 | 8.8 | 7.7 | 9.6 | 3TNV76 | 3 | 1580*810*930 | 300 |
| GNR8.5YM | 8.5 | 11 | 9.4 | 12 | 3TNV82A | 3 | 1580*810*930 | 320 |
| GNR10YM | 10 | 13 | 11 | 14 | 3TNV88 | 3 | 1580*810*930 | 359 |
| GNR12YM | 12 | 15 | 13 | 17 | 3TNV84T | 3 | 1580*810*930 | 422 |
| GNR16YM | 16 | 20 | 18 | 22 | 4TNV84T | 4 | 1580*810*990 | 467 |
| GNR25YM | 25 | 31 | 28 | 34 | 4TNV98 | 4 | 1580*810*990 | 467 |
| GNR32YM | 32 | 40 | 35 | 44 | 4TNV98T | 4 | 1580*810*1165 | 667 |
| GNR40YM | 40 | 50 | 44 | 55 | 4TNV106 | 4 | 1580*810*1165 | 730 |
| GNR45YM | 45 | 56 | 50 | 62 | 4TNV106T | 4 | 1580*810*1165 | 730 |
Diesel engine
a) World most famous brand diesel engine: Yanmar
b) Multi-cylinder in-line or veer engine, 4-stroke, direct injection
c) Naturally aspirated, turbocharged, water cooled or turbocharged with air intercooler
d) Machinery or electronic governing
e) Fuel injection pump
f) Electric motor starting system
g) Forged steel crankshaft, cast iron cylinder and replaceable wet type cylinder liner
h) Low discharge, and low fuel consumption
i) Installed conveniently and maintain easily
Alternator
a) alternator: Leroy Somer, Stamford, or Marathon etc.
b) Inspiration Method: Natural Aspirated or Turbocharged
c) Excitation Way: Brushless Excitation
d) Governor Method: Electrical or Mechanical Governor
e) Cylinder:3L~ 4L
f ) 3ph:star,delta
g) Rated power factor:0.8(lagged)
h) Standard 2/3 pitch windings
i) Voltage Regulation:± 0.5%
j) Exciter type:PRET or Shunt
k) Votagle regulator: AVR (Automatic Voltage regulator)
Control system:
a) Automatic alarm system: the unit has the acousto-optics alarm system and arrestor for any situation as the start defeat, the water is over temperature, the oil pulls down, over speed, over load and over current.
b) Operation display:
1) Unit voltage, tri-phase load current and frequency display
2) Water temperature, oil pressure display
3) Fuel level, fuel temperature display
4) Audible and visual alarm lamps and buzzers
Warranty and Maintenance
a) Do the full power load test for five hours before package.
b) One year or 1000 working hours, whichever comes first.
c) After expiration, we provide spare parts maintenance with low price.
