80kva Silent 64kw Diesel Generator Set With Perkins Engine

US$ 8,695 - 11,459 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Model Number:

GNRP

Shenzhen Genor Power Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name UK

Model Number GNRP

Output Type AC Three Phase

Speed 1500rpm or 1800rpm

Frequency 50Hz or 60Hz

Rated Power 64kw

Rated Voltage 220V/380V, 230V/400V, 240V/415V

Rated Current 116A

Specifications

64kw Diesel Generator Set
-UK Engine & Stamford Alternator
-Low Fuel Consumption
-Electronic Governor
-Globally Servic

80kva Silent 64kw Diesel Generator Set With Perkins Engine

Set Model	GNRP64
Prime at 50HZ, 40°C ambient	64KW 80KVA
Standby at 50HZ, 40°C ambient	70KW 88KVA
Rated Gen-set output	230/400V 50Hz 64kw Generator Price
Rated Relative humidity	≤ 60 %
Dimension (L×W×H)	1950×850×1150mm
Weight	1100kg
Fuel consumption 100% prime load	12.7L/H
Total heat radiated to ambient	/
Structure of Gen-set	The Gen-set adopt integrative structure, engine is fix on high strength steel basic frame, anti vibration instrument between the engine and basic frame, cooling fan have protecting cap, control cabinet and circuit breaker installed on Gen-set
Control system (Optional)	Basic control panel or Advanced control panel with automatically start-up function and other function

engine 1104a-44tg2:

Engine Brand	uk Imported
Engine Model	1104A-44TG2
Governor/Class	/
Cylinder NO.	4
Engine build	Vertical in-line
Fuel spray pattern	direct injection
Aspiration	Turbocharged
Cooling mode	Radiator cooled (enclose water)
Bore and stroke	105×127mm
Compression ratio	18.2:1
Displacement	4.41L
Engine Prime Power at 1500rpm	53KWm
Engine Standby Power at 1500rpm	59KWm
Start-up mode	12V, electric
Battery capacity	/
Starting/Min temperature	/
Lubricating oil consumption	Lubricating oil consumption less than 10% Fuel consumption
Lubrication oil capacity	8.5 litres
Coolant capacity – radiator and engine (40°C)	12.6litres
Exhaust temp – full load prime	/
Exhaust gas flow – full load prime	/
Exhaust gas back pressure max	/
Air flow – radiator (40°C ambient)	/
Pusher fan head (duct allowance) 40°C	/
Air intake – engine– full load prime	/
Standard Air intake temp	25°C
Fuel type	#0 Diesel (Natural temperature)
Filter system	Adopt whole changeable lubricating oil, fuel filter and air filter
Exhaust system	Adopt industrial high efficiency silencer and flexible bellows
