Specifications
Diesel Generator 165kva-UK Engine & Stamford,Leroy Somer
-Low Fuel Consumption
-Electronic Governor
-CE & ISO 9001
Silent Type ! Diesel Generator 165kva
Genset Model |
GNRP120 |
Prime Power(kw/kva) |
120/150 |
Standby Power(kw/kva) |
132/165 |
Rated Current(A) |
216 |
Rated Speed(rpm) |
1500 |
Rated Frequency(Hz) |
50 |
Rated Voltage(V) |
400/230 |
Phase Number |
3 phase 4 line |
Power Factor |
0.8(Laging) |
Voltage Regulation |
AVR |
Genset Structure |
silent canonpy |
Noise Decibel(dB(A)) |
85 |
Net Weight(kg) |
1500 |
Dimensions(L*W*H)mm |
2360*1020*1400 |
Engine data | |
Engine Brand |
uk imported |
Engine Model |
1106C-E66TAG4 |
Fuel consumption(L/h) Full Load |
20.5 |
Cylinder Number |
6L |
Bore * Stroke(mm*mm) |
105*127 |
Displacement(L) |
6.0 |
Exhaust Temp(°C) |
580 |
Lub. Capacity(L) |
19 |
Coolant Capacity(L) |
37 |
Starting Voltage(V) |
12 |
Governor |
Electronic |
Base Fuel Tank |
8 hours |
Optional Supply
1. ATS (Automatic transfer system)
2. AMF Panel
3. Silent canopy (for silent type only)
4. Fuel Tank (8 hours running)
5. Four Protection (high temperature auto shutdown, overload automatic shutdown, low oil pressure automatic shutdown, automatic shutdown phase)
6. Parallel system
7. Remote system
8. Trailer type
9. Soundproof / water proof
10. Lighting tower
Soundproof (Silent ) type
1. Excellent ventilation
2. Oil tank mounted on base frame for 12 Hours working
3. Highly Corrosion Resistant construction
4. Excellent Access for Maintenance
5. Security and Safety
6. 1m<100 dB (open type) <80dB (soudproof)<70dB (silent type)<65dB (super silent)
Trailer type generator (Protable,Mobile Power Station)
1.Two wheels or four wheels for choice.
2.Maintenance room in both sides of the trailer.
3.Well sealed canopy can prevent rain and dust.
4.Equipped with anti-vibration suspension system.
5.Adjustable height, bolted towed rack and booster.
6.Adopt mechanical under props at each corner of the trailer.
7.Full road light system combines with traffic safety standard.
8.Best choice for outdoor power supply or emergency power supply.
9.Mounted with pneumatic and hydraulic pressure brakes, stationary brake and brake lights.
Warranty policy
Guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, Genor will provide the free easy-damageable spare parts of diesel engine caused by our quality of production or raw material. After expiration, Genor provides cost spare parts maintenance of gensets
