With Perkins engine 22kw whole home diesel generator
Introduction:
1)Generator choose famous brand UK Diesel Engine as the dynamic force.
2)The engine has the feature of good power performance,safety,low fuel consumption and good reliability.
3)Our generator sets are widely used as prime or standby power supply in building,bank,supermarket,industrial,factory,fieldwork,oil field,highway and so on.
| Part No. | GNRP20 | ||||
| Frequency | 50Hz | ||||
| Prime Power | 20Kw | ||||
| Standby Power | 22Kw | ||||
| Voltage | 190V~240V/110V~120V;400V~480V/230V~240V | ||||
| Power Factor | 0.8/1 | ||||
| Altenator | Model | PT144F (Stamford ) | |||
| Type | Alternator | ||||
| Prime Power | 20Kw | ||||
| Standby Power | 22Kw | ||||
| Excitation System | Brushless excitation with AVR | ||||
| Insulation Class | H | ||||
| Construction Type | SAE | ||||
| ENGINE | Model | 1003G | |||
| Number of cylinder | 3 | ||||
| Bore×stroke | 100×127mm | ||||
| Compression ratio | 16.5:1 | ||||
| Displacement | 3.0L | ||||
| Specific fuel consumption | ≤210 g/Kw.h | ||||
| Rated speed | 1500 r/min | ||||
| Prime Power | 28Kw | ||||
| Standby Power | 30Kw | ||||
| Starting system | Electric start | ||||
| Cooling system | Closed/Open circle water cooled | ||||
| Starting battery | 24/100AH | ||||
| Operation noise level @7m | 75 dBa | ||||
| ing time | 12 hrs | ||||
| Packing dimensions | 3300×1480×1800 mm | ||||
Control Panel:
1.Auto start when power goes out
2.Auto stop when power comes back on
3.Worldwide technical support with programmable software download
4.Full online documentation
5.Trouble shooting symbols to assist owner on concerns with the generator
6.Safety shutdown feature to protect the engine and generator from damage
7.Totally digital with few points of contact to the engine to increase reliability
8.Exercise features and daily start and stop programmable
Standard configuration of pekins:
1. Starting system: DC alternator is used to start engine
2. Short circuit protection: MCCB air switch
3. Cooling system: combined cooling water tank fitted to meet the requirement of radiation at ambient temperature 40°C
4. Filter system: oil, fuel and air filte
5. Accessories: exhaust elbow, bellow, muffler
