A.C.Synchronous Used Generator in Dubai With Cummins Engine

A.C.Synchronous used generator in dubai with Cummins Engine

Our company is an approved OEM partner. So we can provide genuine generator for sale with very competitive price and comprehensive technical support.

Genset Features:

1. Genuine Cummins industrial diesel engine

2. Radiator 40°C max, fans are driven by belt, with safety guard

3. Genuine stamford. Leroy somer, marathonm, engga alternator

4. Choice of manual/auto and AMF control panels and protection systems

5. Digital auto-start panel

6. Anti Vibration Suspension Absorber

7. Dry type air filter, fuel filter, oil filter

8. 10-hour operation base tank

9.Mould case circuit breaker

10. 24V DC start motor and storage battery

11. 24V charge alternator

12. 24V batteries, rack and cable

13. Rippl;e flex echaust pipe, exhaust siphon, flange, and muffler

14.   Comply with ISO and CE standards

15. All generator sets are gone through rigorous testing before beging released to the market place, including 50% load, 75% load, 100% load and all protection function(over speed stop, high water temperature, low oil pressure, battery charging fail, emergency stop)

 diesel engine:

Engine: Cummins diesel engine

Cooling method: closed water cooling

Starting method: electric start

Rated speed: 1,500/1,800rpm

Noise level:   68dB at 7m away

Alternator:

Brand: Stamford,LeroySomer, Marathon,Engga

Rated output: 25KVA-1250KVA

Rated voltage: Rated  220V/380V, 230V/400V, 240V/415V

Power factor: 0.8

Phase: 3-phase, 4-wire

Rated speed: 1,500rpm/1,800rpm

Excitation: harmonic excitation or phase compound or brushless

Voltage regulation: automatic

1.0% voltage regulation (maximum) in static conditions

Protection class:  IP21-23

Control panel

The generator control panel is manufactured locally

Standard engine instrumentation

Voltmeter with selector switch

Ammeter with selector switch

Frequency meter

Current transformers

Instrument fuses duly wired and ferruled

Mcb of suitable rating with overload and short-circuit protection

With AMF control panel or with ATS (automatic transfer system)

With EPA certification

Accessories

1) Standard accessories: Standard 40 radiator mounted on skid, Common steel frame, circuit breaker, damper, exhaust silencer, flexible pipe, battery and connecting wires, Standard tools kit, operation manual and document.

2) Optional accessories: Engine coolant and oil heater, alternator space heater, cooling for heat exchanger, communication interface, battery charger by main supply, daily fuel tank, ATS and paralleling system, soundproof canopy and moving trailer.
