Diesel Power Electirc 400kw Generator Set With Cummins Engine

1.Main technical data of gensets

1.1

Model

GNRC400

1.2

Prime power

400KW

1.3

Prime voltage

254V/440V

1.4

Speed

1800 rpm

1.5

Weight

3950kg

1.6

Overall dimension

3150×1000×2150mm (just for reference)

2.Main technical data of engine

Cummins engine, 4 stroke. DC start. Come with sea water pump, heater exchanger and

expansion water tank, open-cycle cooling.

2.1

Brand

CUMMINS

2.2

Model

KTA19-DM

2.3

Prime power

463KW

2.4

Governor type

Electronic

2.5

Configuration

4 cycle , 6 cylinder in line

2.6

Cooling method

By heater exchanger

2.7

Bore/Stroke

159×159 mm

2.8

Displacement

19.0L

2.9

Starting method

Electric

2.10

Fuel consumption

203g/kw.h

3. Main technical data of alternator

Alternator is selected the new type brushless alternator designed by US Marathon Electric,

which has a unique design, advanced structure, small size, light weight, excellent performance,

reliable running and easy-to-use operation.

3.1

Brand

MARATHON

3.2

Model

MX-H-400-4

3.3

Prime power

400KW

3.4

Configuration

Brushless , self-exciting

3.5

Prime voltage

254V/440V

3.6

Frequency

60 HZ

3.7

Power factor

0.8(lagging)

3.8

Phase/wire

3 phase 4 wires

3.9

Isolation

H
