Full-automatic block forming machine/automatic interlocking brick machine
hydraulic brick making machine/ Concrete Hollow Block Making Machine
It adopting synchronization vibration insures the products well-distributed.
2.Itequipped with fault diagnosis system,which can eliminate the fault by the warning signal.
3. The machine combined with long-distance controlling system that could achieve scrutiny, controlling, diagnosis when it working.
4.Itis equipped with PLC intelligent control system and the function of Man-machine interface.
5.The control system equipped with complete logic control, production program, malfunction diagnosis system and remote control function. So it doesn’t need a professional person but a simple training to the operator.
B.Terms and conditions
1. Equipment is designed for an overall production capacity of 86400 bricks in a shift of 8 hours.
2. In the press, hydraulic cylinder operation time work out to 12-15 seconds / cycle depends upon operator efficiency.
3. The dye in the mold is made with replaceable liners of hardened alloy steel. The life of liners is 86.400 bricks and this figure would vary depending on the soil hardness which is found to differ from place to place.
4.Since the equipment operates in dusty condition proper care has to be taken by you to prevent dust entry into oil.
Technical Parameters
Cacpacity |
1920-10800bricks/h |
Power (Motor) |
32kw |
Load |
30 Tons |
Brick Size |
240X115X53mm |
Max Size |
390×240×190 mm |
System |
Hydraulic, Automatic, Rotary Table, Three Stationed PLC Controlled |
Table Rotation |
Hydraulic Motor (Automatic) |
Mix Feed |
Conveyor or Manual |
Brick Removal |
Manual |
Raw Material |
Fly ash, Iron Oxide Lime Sludge, Quarry Waste Etc. |
Weight |
9.8ton (Approximately) |
Mold:We can produce any kinds of mouldsaccording to your need.
Related pictures of brick forming machine
