The brief introduction of Automatic Roll die cutting machine cutting paper cup paper die cutting machine
OR-900 automatic indentation roll paper die-cutting mahcine.It adopts micro-computer,human-computer control inerface,servop0sitioning,alternating current fequency converter,automatic counting,manual pneumatic lock plate,phtotelectric correcting deviation system,eletromagnetic clutch,centrilized oil lubrication,overload protection and distinctive gearing.
The features of Automatic Roll die cutting machine cutting paper cup paper die cutting machine
2. Cut the roll paper to small blank directly control the waste the paper Wastage rates small than nzrmal cutting machine
3. Strong frame easy operate
The Parameters of Automatic Roll die cutting machine cutting paper cup paper die cutting machine
| Product name | Automatic Roll die cutting machine cutting paper cup paper die cutting machine |
| General power | 7.5kw |
| Total Power of Electric Machinery | 11kw |
| Paper request | 135~500g/square meter |
| Voltage supply | 220v50hz/380v50hz or customized |
| Conditions for Using | Draft,dry;suggested temperature for using:10-25° |
| Roll Paper Size | Diameter<1400mm;width<1000mm |
| Die-cutting Precision | 0.10mm |
| Rated Die-cutting rate | 60-100 times/minute 900-1600pcs/min |
| Maximum Die-cutting Rate | 110 times/minute |
| Maxmum Die-cutting Rressure | 120T |
| Maxmum Die-cutting Size | 900*500mm |
| Minum Die-cutting size | 490 * 400mm |
| Weight | 6000kgs |
| Dimension | 4000*1700*1700mm |
| Air supply requirement |
Working pressure:0.5-0.6mpa Gas volume:0.1 m3/minute |
Automatic Roll die cutting machine cutting paper cup paper die cutting machine
Automatic Roll die cutting machine cutting paper cup paper die cutting machine
Automatic Roll die cutting machine cutting paper cup paper die cutting machine
packaging&shipping&payment
| Packong Detail | Strong wooden case |
| Delivery Detail | 3-7days after receiving the prepayment |
| Mode of transportation | By sea,By Air,By Express |
| Port of shipment | Main port in China mainland |
| Terms of payment | L/C,T/T,Western union,Paypal/Trade Assurance |
