Home > Industrial Equipment & Components > Ventilation Equipment > Ventilation Fan > Greenhouse Chicken House Warehouse Workshop Cooling Fan
Greenhouse Chicken House Warehouse Workshop Cooling Fan
US$ 70 - 230
MOQ: 1 Set
Key Specifications
Get Latest Price
Electric Current Type:
AC
Mounting:
Wall Fan
Blade Material:
Stainless Steel
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Push-pull Centrifugal Ventilation FanUS$ 80 - 120MOQ: 5 Sets -
High Quality Push-pull Centrifual FanUS$ 150 - 160MOQ: 1 Set
-
Auto Push-pull Fan/ Exhaust FanUS$ 150 - 160MOQ: 1 Set
-
Ventilation Fan for Greenhouse and Poultry With PusherUS$ 150 - 160MOQ: 1 Set
-
Push-pull Fan/Electric Ventilation Fan/US$ 150 - 160MOQ: 1 Set
Electric Current Type
AC
Mounting
Wall Fan
Blade Material
Stainless Steel
Place of Origin
Hebei, China
Brand Name
Yunpeng
Model Number
YP-1100A
Voltage
380V/220V
Power
1.1KW
Air Volume
38000m3/h
Speed
460rpm
Certification
CE, GS
After-sales Service Provided
No overseas service provided
Specifications
1) drop hammer type2) stainless steel blade
3) gavalnizded sheet frame
4) Sanlux belt&Mitsubishi belt
5) easy to install
Professional manufacturer of exhaust fan, ventilation fan, roof fan, centrifugal fan, air cooler and cooling system.
Stainless steel blades, big air volume, CE certificate, low price.
| Item | YP(A)-drop hammer exhaust fan |
| Frame | galvanized steel sheet, anti-corrosive, durable |
| Frame thickness | 1.0mm for the top and 0.8mm for the other sides |
| Motor | Siemens motor and Chinese motor are available, high efficient and energy-saving with CCC certificate. Protection class: IP55. Insulation class: F. The voltage, frequency, power and phase can be customized. |
| Motor RPM | 1400r/min |
| Noise | <70db |
| Blades No. | 6 pcs |
| Blade material | BA 430 stainless steel. Thickness: 1.2mm |
| Blade instruction | weight difference between blades is less that 0.5g, blades will go through balance test after assembled which can assure steady running and even airflow |
| Shutter | made of high strength hot-galvanized steel sheet, dustproof and waterproof |
| Shutter thickness | 0.45mm |
| Shutter linkage | aluminum |
| Spring | stainless steel |
| Swung drop hammer | made of high quality nylon, stable performance, guaranteeing the shutters open and close flexibly |
| Belt | China famous brand Sanlux belt, Japan Mitsubishi belt, Korea Dongil belt |
| Housing | galvanized steel. Thickness: 1mm |
| Net guard | two half pieces, made of hard-drawn wire, designed as door-type, which is convenient for maintaining |
| Small belt pulley | cast iron |
| Big belt pulley | made of aluminum magnesium alloy by injection moulded, reducing the weight of blade and impeller, high corrosion resistance. Blast-sanding treatment for attractive appearance, eliminating internal stress to improve its own rigidity and stability, high strength |
| Belt tensioner | made of high quality nylon or aluminum magnesium alloy, avoiding belt loosening or dropping off, extending service life and avoiding distortion |
| Belt impeller | made of aluminum magnesium alloy by injection moulded, adopting more stiffening rib, processed by sandblasting,, eliminating the internal stress, high intensity, low noise, long service life |
| Motor base | both 1.5 HP and 1 HP motor can be installed |
| Motor hole | installation hole of motor and nut are all six angles instead of the roundness |
| Bearing | imported double-row bearing, super mute, high intension and durable, adopting special waterproof design, high intension, low noise, maintenance-free and long service liife |
| Guarantee period | 1 year, easy broken parts are offered free of charge during this period |
| Model specifications | Diameter of blades | Blade rotational speed | Motor rotational speed | Air flow | Total pressure | Noise | Input power | Rated voltage | Height | Width | Thickness |
| mm | rpm | rpm | m3/h | Pa | db | W | V | mm | mm | mm | |
| YP-710A | 710 | 630 | 1400 | 20000 | 60 | ≤70 | 370 | 380 | 800 | 800 | 400 |
| YP-750A | 750 | 620 | 1400 | 28000 | 65 | ≤70 | 550 | 380 | 900 | 900 | 400 |
| YP-900A | 900 | 610 | 1400 | 30000 | 70 | ≤70 | 750 | 380 | 1000 | 1000 | 400 |
| YP-1000A | 1000 | 600 | 1400 | 32500 | 70 | ≤70 | 750 | 380 | 1100 | 1100 | 400 |
| YP-1100A | 1100 | 460 | 1400 | 38000 | 70 | ≤70 | 1100 | 380 | 1220 | 1220 | 400 |
| YP-1250A | 1250 | 439 | 1400 | 44000 | 56 | ≤70 | 1100 | 380 | 1380 | 1380 | 400 |
| YP-1400A | 1400 | 325 | 1400 | 55800 | 60 | ≤70 | 1500 | 380 | 1530 | 1530 | 400 |
