HF RFID GATE READER
HYL50C
Specification
HYINTECH Automatic Attendance System is barrier-free and automatically check-in device designed for conference, exhibition and other events. This system is integrated with HYINTECH high-performance reader and infrared sensor, can rapidly and accurately identify personnel in/out with or without cards. It can identify ISO/IEC15693 and ISO18000-3 tags. The widest identification distance can be up to 120 cm (exact distance depends on tag and working environment ).
Main Features
Ø Working Frequency: 13.56Mhz
Ø Compatible Protocol: ISO15693 and ISO18000-3 protocol
Ø Passage Width: 70~120cm (adjustable according to user’s demands)
Ø Radio Frequency Power: 3~8W(adjustable)
Ø With noise detection function to detect electromagnetic interference around
Ø Integrated infrared sensor cutting analysis, can rapidly and accurately identify personnel in/out with or
without cards and to prevent their followers
Ø Communication Interface: Ethernet and RS232 port.
Ø Built-in sound and light alarm/prompt function.
Ø Power Supply: AC 100~240V
Ø Transparent acrylic design, looks beautiful and elegant
Key Parameters
Module |
HYL50C |
Working Frequency |
13.56Mhz |
Compatible Protocol |
ISO15693 |
RF Power |
3~8W (Adjustable) |
EMI Detection |
Support |
Cascade Operation |
Support |
Passage Width |
70~120cm |
Power Supply |
AC 100~240V 50~60Hz |
Maximum Power Consumption |
32W ( Rated Power 25W ) |
Housing Material |
Acrylic, Metal Plate |
Waterproof |
Not |
Dimension |
Overall: 1556*545*180mm |
|
Antenna: 1550*490*72mm Pedestal: 545*180mm | |
Weight |
20kg/pc |
